34
If your cooker hood is going to be used in extraction mode, then you should connect the ducting hose to the ceiling
adaptor at this point.
Fix the upper chimney section to the hanging plate, using the 4×self tapping screws(4*6mm).
Slide the lower chimney section onto the angle bars and raise it until it sits just below the upper chimney section.
Lift the main body of the cooker hood onto the angle bar and then fix it into position using the 16×M5 screws.
IMPORTANT: This stage of the installation process MUST be completed by two people.
IMPORTANT: The 16×M5 screws MUST be securely tightened.
