OPERATION
These versatile CQ devices can be controlled by way of either another CQ device, a remote latching contact
closure, a Juice Goose RC5 accessory unit or the switch on the CQ device itself (except CQ 1, CQ5 and CQ50).
CQ DEVICES
- Any CQ device can operate in concert with others. Each can be a master (except CQ1, CQ5 or
CQ50) or slave unit. Any number of CQ devices can be connected in a daisy chain fashion to operate as a
power sequencing system.
REMOTE CONTACT CLOSURE
- As one option, to control the sequencing function, the Signal Input for the first
CQ device can be connected to a latching contact closure (see previous section “Remote Switch Connection”).
Juice Goose recommends use of a double throw device in order to maintain one of two contact closures at all
times. AV control devices such as those produced by Crestron may have relay cards that can serve this func-
tion.
RC-5 REMOTE ACCESSORY
- Juice Goose offers, as an accessory, the RC-5 Remote Control/Monitor. These
devices provide sequence control as well as indicators to show the status of the power sequencing operation.
The RC-5 connects directly to the Signal Input of the first CQ device.
SEQUENCE SWITCH (Not including the CQ 1, CQ5 or CQ50)
- Without a contact closure on the Signal Input,
the switch on the CQ device will control its operation. Switches on the CQ 2200, CQ 3000 and CQ PD1-4 have
three positions: Sequence up, Sequence Down and Manual On. If the product in question is not a slave in the
CQ network, the Sequence Up and Down positions will activate the sequence process for that CQ unit and
cause it to activate any units connected to its Signal Output. In the event of a failure of a particular CQ unit, the
Manual On switch position allows activation of the CQ device. (Note: the Manual On option does not provide
sequencing). The CQ 1515 and CQ1520 have a two position sequence switch and a second, recessed Manual
On switch on the front panel of the chassis.
MONITORING
Some CQ Series devices have a number of LEDs on the chassis to allow real time monitoring of the device’s
operation. The LED labeled “PROC” indicates the control program is running. That LED blinks blue and red un-
der normal conditions. Blinking red indicates a fault with the surge protection circuitry. Solid blue or off indicates
a fault with the sequence control circuitry. “POD” LEDs light to indicate activation of power to a corresponding
group of power outlets, indicating a sequence stage has been completed and the corresponding POD has
power.
Juice Goose offers RC-5 remote control and monitor accessories that provide indications of sequence operation
and completion. For more information about the RC-5, contact your Juice Goose dealer, refer to the Juice
Goose product catalog or visit www.juicegoose.com.
RX SERIES SURGE PROTECTION
CQ 1515-RX and CQ 1520-RX feature high level power line protection. This RX power protection technology is
particularly valuable because it works against common mode (ground line) as well as normal mode (line to neu-
tral) events. While it protects against dramatic surge events of up to 6,000 volts at 3,000 amps on hot and neu-
tral, it also limits ground line surges to one-half (0.50) volt to prevent operating faults of digital processing equip-
ment. Power protection circuitry in the CQ Series-RX includes a differential transformer, series inductor, high
levels of filtering capacitance and control circuitry providing protection from dangerous surges, high frequency
interference, building wiring faults and over voltage.
AC Power Filtration @ 30 MHz…………………………………….…...….80dB Common Mode, 60dB Normal Mode
Transient Energy Absorption…………………………….…………………………...……………………….1,020 Joules
Max AC Surge Let Through……………………………....10 Volts Normal Mode, 1/2 Volt Common Mode (Ground)
External Fault Protection……………………………………….....Open Ground, Hot-Neutral Reversal, High Voltage
