MOUNTING AND PLUG IN
CQ 1515 & CQ 1520 — Mount the CQ-1515 or CQ-1520 to a 19” wide rack with metal mounting rails. Use ap-
propriate rack mounting hardware. Plug the power cord into a grounded outlet. Do not defeat the grounding
feature of the power cord.
CQ 50 - This product can be mounted to a flat, stable surface using four holes on the two mounting side
flanges. Be sure to place the product near an AC receptacle and to leave room for connection of the CQ control
cable(s). Plug the cord into a grounded outlet. Do not defeat the grounding feature of the power cord.
HARD WIRED INSTALLATION
These products were designed to be installed only by qualified electrical technicians. Failure to follow correct
installation techniques and instructions could result in equipment damage and/or personal injury. CAUTION: Be
certain power has been turned off at the breaker panel or disconnected before installation. (ATTENTION: cer-
tains power a été désactivé sur le panneau de disjoncteur ou déconnecté avant l'installation.)
CQ 1 - This product should be installed in a three gang utility box mounted inside a wall. The installation process
may vary depending on whether the installation is in new or retrofit construction. Fit the utility box into the space
where the CQ 1 will be installed. Pull the main power cable and the RJ45 signal cable(s) into position inside the
utility box. Connect the power feed to the corresponding colored wires on the CQ 1 using wire nuts or another
acceptable method. Plug the input signal cable into the Input port on the CQ1 and the output cable into the Out-
put port. Install the CQ 1 enclosure and cover plate onto the utility box with the screws provided with the unit.
CQ 2200 & CQ 3000 are intended to be hardwired to a main utility power supply with power cable routed
through conduit. A “squeeze” type conduit connector is assembled onto the CQ back box specifically for this
purpose. A power line strain relief is also included in the box with the CQ device in case alternate power connec-
tion is necessary.
These two CQ Series models have front panel and a back box construction that are held together with seven
screws. To begin installation, remove the screws that hold these two pieces together. The back box has four
holes in the back surface. These holes are large enough to accommodate mounting screws or bolts (not in-
cluded) to hold the CQ device securely to a stable, flat mounting surface, such as a wall. At least two screws or
bolts should be used to mount the back box.
After the back box is secured, feed the cable that is connected to the desired power source through the hole in
the side of the back box. CQ2200: Securely crimp a connector (provided) to the end of each wire lead (hot,
neutral and ground). Press the connectors onto the appropriate locations on the circuit board as labeled.
CQ3000: Connect each wire lead to the appropriate position on the terminal block and tighten securely. Attach
the front panel (containing the circuit board) to the back box using all seven screws. Gently pull excess power
cable out of the box by tugging slightly on the cable from the outside of the box. Insert conduit into squeeze con-
nector and tighten the connector to hold the conduit in place.
CQ-PD1-4 - The CQ-PD1-4 has two slotted side brackets that can be relocated along the length of the chassis.
Use only appropriate hardware (not included) and use four mounting holes to secure the device. The wire har-
ness should be connected directly to a circuit breaker panel or to an appropriate junction box.
