. INTERFACES
Interface connections play a crucial role in the world of electronics, similar to buttons in user interfaces.
They enable communication and power supply between dierent electronic components. The following
connections can therefore be found in the interface area on our Explorer Board:
SPI (Serial Perhipheral Interface): This connection is used for fast serial data transmission. It typically
consists of four lines: MISO (Master In, Slave Out), MOSI (Master Out, Slave In), SCK (Serial Clock) and SS
(Slave Select). SPI is ideal for situations where a high data transfer rate is required, such as when controlling
LCD displays or SD cards.
I2C (Inter-Integrated Circuit): I2C is a two-wire interface consisting of a data line (SDA) and a clock line
(SCL). It is commonly used in microcontroller applications for communication between dierent integrated
circuits. Its simplicity makes it ideal for applications where not many GPIO pins are available.
UART (Universal Asynchronous Receiver/Transmitter): This interface enables asynchronous serial communication via two lines: TX (Transmit) and RX
(Receive). UART is oen used for communication between microcontrollers and computers or for connecting modules such as GPS receivers or Bluetooth
modules.
3.3 V and 5 V connections: These connections provide the power supply for electronic components. 3.3 V is oen used for modern microcontrollers and
sensors, while 5 V is oen found in older or more power-hungry devices.
Connections for crocodile clips: These connectors are ideal for temporary connections or for test purposes. They enable quick and easy connection to
various components or measuring devices without soldering. There are a total of five such connectors on the Explorer Board, which can be used flexibly for
a variety of applications.
Each of these connections has its specific application and meaning in electronics, similar to how dierent types of buttons in a user interface have dierent
functions. They provide the necessary flexibility and functionality for setting up and expanding electronic systems.
14
