1. Thoroughly read and understand this entire instruction
manual for safety information and assembly, operation,
and maintenance instructions. Failure to follow the
information provided in this manual may cause serious
injury or death.
2. Keep bystanders a safe distance from the work area and
material lift path while in use. Keep children away. Do
not allow children to access or operate this material lift.
3. Wear proper clothing and safety gear. When operating
this material lift, wear a hard hat, safety glasses, steel-
toe shoes, and gloves.
4. This material lift is designed and intended for use by
properly trained and experienced personnel only. Learn
how to operate this lift properly and safely. If you are not
familiar with the proper and safe operation of this lift,
do not use it. Follow proper and safe lifting practices.
5. Do not use this material lift for purposes other than its
intended use, as outlined in this owner’s manual. If used
for other purposes, JET disclaims any real or implied
warranty and holds itself harmless from any resulting
injury or property damage.
6. Do not attempt to lift any load while the SkyHyker is in
the travel (horizontal, non-load) position.
7. Be sure the mast pin and mast/legs locking plate are
in place and all four caster wheels are locked before
attaching to or lifting a load.
8. Always operate this material lift while standing between
the two rear, shorter legs and behind the mast.
9. Do not use this material lift to lift, lower, support, or
transport people.
10. Do not lift, lower, or support loads over the top of people.
11. Never allow anyone under the mast T-bar or an elevated
load.
12. Do not exceed the rated load capacity of the material
lift. Follow the Load Ratings as outlined in Section 1.7
LOAD RATINGS.
13. When lifting or lowering loads using the load winch, only
raise the mast T-bar as high as needed for the job being
performed.
14. When lifting or lowering loads using the load winch,
and the mast T-bar height is below 20 feet (6.1 m), the
maximum load capacity is 2000 lbs (907 kg). Follow the
load ratings specied in Section 1.7 LOAD RATINGS.
15. When lifting or lowering loads using the load winch, and
the mast T-bar height is above 20 feet (6.1 m), the max-
imum load capacity is 1500 lbs (680 kg). You must also
use the supplied guy wires to add lateral stabilization
to the mast. Follow the load ratings specied in Section
1.7 LOAD RATINGS.
16. When lifting or lowering loads by telescoping the mast,
the maximum load capacity is 1000 lbs (453 kg). Do not
use this method if the mast T-bar starts or ends above
20 feet. Do not use this method if lifting or lowering
loads over 1000 lbs. Follow the load ratings specied
in Section 1.7 LOAD RATINGS.
17. When jack lifting using the telescoping mast, the maxi-
mum load capacity is 1000 lbs. (453 kg) and can only be
used with the mast T-bar below 20 feet (6.1 m). Follow
the load ratings specied in Section 1.7 LOAD RATINGS.
18. Before jack lifting a load, the load must be secured and
supported independent of the material lift. Never jack
lift an unsecured load as it may shift and fall, causing
severe injury or property damage.
19. Avoid sideways cable slip. When winding the cable under
load, make sure a minimum space of 2-times the cable
diameter remains on the drum ange.
20. Always leave at least ve wraps of the cable on the drum.
Failure to do so may break the cable connection to drum
and result in serious injury or property damage.
21. Always use proper couplings when connecting the winch
cable hook to a load.
22. Do not use any attachments to extend the length of the
winch cable.
23. Be aware of the pinch point at the mast interaction with
the square tube.
24. Make sure winch brake is properly adjusted before using
lift.
25. Make sure cable wind/loop is in the correct orientation.
The cable should always enter and exit the spool on the
spool side away from the mast (not facing the mast).
See Figure 2-1.
26. Always inspect the material lift and cable for damage
prior to use. If lift is damaged, repair before use. Do not
attempt to lengthen or repair cables. If cable is kinked,
frayed, worn, or damaged, replace before use. Replace
cables with factory replacement cables only. Do not use
any other type of cable.
2 Safety Information
3 | Chapter 2: Safety Information
