Figure 7-26: Securing Load Cable Hook on Hook Bracket
7.7.2 Moving with Mast in Horizontal
Position
If moving the material lift through lower doorways or through
areas with overhead hazards and obstructions, you must
adjust the mast to the horizontal position.
1. Adjust the mast to the Travel (horizontal, non-load) position.
Follow the steps under Section 7.8 ADJUSTING MAST TO
TRAVEL (HORIZONTAL, NON-LOAD) POSITION FOR MOVING
AND TRANSPORT.
2. Make sure the caster wheels are unlocked (see Section
7.10 LOCKING CASTERS).
3. If moving the material lift though narrow doorways or pas-
sageways, you must adjust the legs to a narrower stance.
To do this, lift and swing open the red mast/legs locking
plate (see Figure 7-27). This unlocks the base assembly
legs. Pivot legs inward to their narrowest position. Swing
the red mast/legs locking plate back into place. Make sure
it drops into the locked position (see Figure 7-28).
4. Carefully move the material lift to the desired location.
Figure 7-27: Mast/Legs Locking Plate Open
Figure 7-28: Pivot Legs to Closed Position
7.7.3 Moving Vertically to Higher or
Lower-Level Work Site Locations
Moving the entire material lift to a higher or lower-level work
site location will require the use of a crane.
1. Make sure the material lift is in the horizontal position. See
Section 7.8 ADJUSTING MAST TO TRAVEL (HORIZONTAL,
NON-LOAD) POSITION FOR MOVING AND TRANSPORT.
2. Make sure all pins are in place and secured.
3. Make sure parts/accessories drawer is closed and secured
with locking pin.
4. Place the load cable hook securely into the hook bracket
as shown in Figure 7-29. Tighten the load winch cable to
remove slack.
Use proper and appropriately-rated rigging and
safe lifting practices when using a crane to lift and
move the SkyHyker material lift.
JET TOOLS • SKY25 SKYHYKER MATERIAL LIFT | 20
Continued
