21
Figure 32
11. Remove belt through lower access door.
12. Reverse above procedure to install belt and re-
position spindle.
NOTE: Make sure:
to place cover (D, Figure 30) onto spindle
before inserting spindle into headstock.
to insert spindle lock with its spring (E,
Figure 30) before tightening cover.
that right-side bearing is properly seated in
its recess in the headstock.
that spindle sensor collar (C, Figure 29) is
positioned over the sensor before
tightening setscrew.
that spindle pulley is aligned with motor
pulley.
not to overtighten handwheel when re-
installing.
13.0 Recommended Lathe Speeds (per diameter of workpiece)
Diameter of Work Roughing RPM General Cutting RPM Finishing RPM
Under 2” 1520 3000 3000
2” to 4” 760 1600 2250
4” to 6” 510 1080 1500
6” to 8” 380 810 1125
8” to 10” 300 650 900
10” to 12” 255 540 750
Table 2
