Index No. Part No. Description Size Qty

245 ............. ** .................................. Socket Head Button Screw .......................................... M5x10 ............................. 2

246 ............. ** .................................. Socket Head Cap Screw .............................................. M8x10 ............................. 2

248A .......... JWJ8HHBLK-248A ...... Lifting Bar Assembly .................................................... ........................................ 1

249 ............. ** .................................. Hex Nut ........................................................................ M12 ................................. 1

251 ............. JWJ8HHBLK-251 ........ POM Strip .................................................................... ........................................ 1

252 ............. ** .................................. Pan Head Machine Screw ............................................ M4x10 ............................. 4

253.. ........... ** .................................. Socket Set Screw ......................................................... M5x8 ............................... 1

254.. .......... ** ............................... Rabbeting Arm ......................................................... ...................................... 1

255 ............ JWJ8HHBLK-255 ...... Ruler ........................................................................ ...................................... 1

256.. ........... ** .................................. Hex Cap Screw ............................................................ M8x35 ............................. 2

259A.. ........ JWJ8HHBLK-259A ...... Spring Housing Assembly ............................................ ........................................ 1

261 ............. ** .................................. Pan Head Machine Screw ............................................ M4x12 ............................. 3

263 ............. ** .................................. Socket Set Screw ......................................................... M6x10 ............................. 2

264 ............. JWJ8HHBLK-264 ........ Warning Label for Blade Guard ................................... ........................................ 1

265A .......... JWJ8HHBLK-265A ...... Blade Guard Assembly ............................................... ………….……… .............. 1

266 ............. JJ6HHBT-081 .............. Knife Insert Screw ........................................................ M5x12 ........................... 36

267 ............. 1791212 ....................... Knife Inserts (sold in sets of 10) ….………………. ....... ...................................... 36

268 ............ JJ6HHBT-085 ............ Star Point Screwdriver ............................................. T20 ................................ 2

270 ............. ** .................................. Flat Washer .................................................................. 5 mm ............................... 2

271 ............. JWJ8HHBLK-271 ........ Large Flat Washer ........................................................ 10 mm ............................. 5

272 ............. ** .................................. Lock Washer ................................................................ 10 mm ............................. 4

273 ............. ** .................................. Socket Head Cap Screw .............................................. M10x20 ........................... 3

274 ............. JWJ8HHBLK-274 ........ Push Block ................................................................... ........................................ 2

275 ............. JET750-55 ................... Hex wrench .................................................................. 2.5mm ............................. 1

276 ............. TS-152704 ................... Hex wrench .................................................................. 3mm ................................ 1

277 ............. TS-152705 ................... Hex wrench .................................................................. 4mm ................................ 1

278 ............. TS-152706 ................... Hex wrench .................................................................. 5mm ................................ 1

279 ............. TS-152707 ................... Hex wrench .................................................................. 6mm ................................ 1

280 ............. TS-227D081 ................ Hex Wrench ................................................................. 8mm ................................ 1

281A .......... JWJ8HHBLK-281A ...... Cutterhead, Helical Body Assembly ............................ ....................................... 1

282 ............. ** .................................. Pan Head Machine Screw ............................................ M5x20 ............................. 2

283 ............. ** .................................. Lock Washer ................................................................ 5 mm ............................... 2

284 ............. JWJ8HHBLK-284 ........ Blade Guard Base ........................................................ ........................................ 1

300A .......... JWJ8HHBLK-300A ...... Fence Assembly-Complete .......................................... ........................................ 1

301 ............. JWJ8HHBLK-301 ........ Special Nut ................................................................... ........................................ 1

302A .......... JWJ8HHBLK-302A ...... Bracket Assembly ........................................................ ........................................ 1

305 ............. JWJ8HHBLK-305 ........ Locking Handle ............................................................ ........................................ 2

306 ............. JWJ8HHBLK-306 ........ Thin Hex Nut ................................................................ M12 ................................. 6

307 ............. ** .................................. Flat Washer .................................................................. 12 mm ............................. 2

308 ............. JWJ8HHBLK-308 ........ Two Ends Bolt .............................................................. ........................................ 2

309 ............. JWJ8HHBLK-309 ........ Fence Bracket .............................................................. ........................................ 1

310A .......... JWJ8HHBLK-310A ...... Locking Sleeve Assembly ............................................ ........................................ 1

312 ............. JWJ8HHBLK-312 ........ Spring Pin ..................................................................... 4x12 ................................ 2

313A .......... JWJ8HHBLK-313A ...... Locating Plate Assembly .............................................. ........................................ 1

315 ............. JWJ8HHBLK-315 ........ Locking Plate ................................................................ ........................................ 1

316 ............. JWJ8HHBLK-316 ........ Tilt Plate ....................................................................... ........................................ 1

317 ............. ** .................................. Hex Nut ........................................................................ M10 ................................. 4

318 ............. JWJ8HHBLK-318 ........ Cone Screw .................................................................. ........................................ 4

319 ............. ** .................................. Flat Washer .................................................................. 6 mm ............................... 2

320 ............. ** .................................. Socket Head Cap Screw .............................................. M6x12 ............................. 2

321 ............. ** .................................. Hex Nut ........................................................................ M8 ................................... 1

322 ............. ** .................................. Hex Cap Screw ............................................................ M8x20 ............................. 1

323 ............. JWJ8HHBLK-323 ........ Support Bar .................................................................. ........................................ 1

324 ............. ** .................................. Hex Cap Screw ............................................................ M8x35 ............................. 1

326A .......... JWJ8HHBLK-326A ...... Fence Hinge Axile Assembly ....................................... ........................................ 2

327A .......... JWJ8HHBLK-327A ...... Hinge Axile Assembly .................................................. ........................................ 1

331A .......... JWJ8HHBLK-331A ...... Fence Body (PTFE) Assembly ..................................... ........................................ 1

333A .......... JWJ8HHBLK-333A ...... Pad Block Assembly .................................................... ........................................ 2

334 ............. ** .................................. Socket Head Flat Screw ............................................... M4x10 ............................. 4

335A .......... JWJ8HHBLK-335A ...... Handle Bar Assembly ................................................... ........................................ 1

337.. ........... ** .................................. Socket Head Cap Screw .............................................. M10x35 ........................... 2

** These parts are shown for reference only and are not available for order individually. Non-proprietary parts, such

as fasteners, can usually be found at local hardware stores.
