13.2 JWJ-8HH-BLK Jointer Assembly – Parts List

Note: Assemblies are highlighted in gray.

Index No. Part No. Description Size Qty

101A .......... JWJ8HHBLK-101A ...... Foot Assembly ............................................................. ........................................ 4

102 ............. ** .................................. Hex Nut ........................................................................ M10 ................................. 6

103A .......... JWJ8HHBLK-103A ...... Base Cabinet Assembly ............................................... ........................................ 1

104 ............. ** .................................. Pan Head Machine Screw ............................................ M4x10 ............................. 1

105 ............. JWJ8HHBLK-105 ........ Switch ........................................................................... KJD17B 230V ................. 1

106 ............. JWJ8HHBLK-106 ........ Dust Port ...................................................................... ........................................ 1

107 ............. ** .................................. Socket Head Button Screw .......................................... M5x10 ............................. 4

108 ............. ** .................................. Hex Nut ........................................................................ M8 ................................... 4

109 ............. ** .................................. Lock Washer ................................................................ 8 mm ............................... 4

110 ............. JWJ8HHBLK-110 ........ Large Flat Washer ........................................................ 8 mm ............................... 3

111 ............. ** .................................. Nylon Lock Hex Nut ..................................................... M8 ................................... 1

112A .......... JWJ8HHBLK-112A ...... Lock Block Assembly ................................................... ........................................ 1

113 ............. ** .................................. Flat Washer .................................................................. 8 mm ............................... 7

115 ............. JWJ8HHBLK-115 ........ Door ............................................................................. ........................................ 1

116 ............. JWJ8HHBLK-116 ........ Power Cord SJT14AWGx3C, 6-15P/230V ................... .................. ……………….1

117 ............. JWJ8HHBLK-117 ........ Motor Cord SJT14AWG x 4C，1.20m ......................... ........................................ 1

118 ............. JWJ8HHBLK-118 ........ Strain Relief .................................................................. M20x1.5 .......................... 2

119 ............. JWJ8HHBLK-119 ........ Motor Pulley ................................................................. ........................................ 1

120 ............. ** .................................. Socket Set Screw ......................................................... M6x16 ............................. 2

121 ............. JWJ8HHBLK-121 ........ Motor Assembly ........................................................... 2HP,230V ....................... 1

121C .......... JWJ8HHBLK-121C…..Motor Fan Cover (not shown) ......................................... ...................................... 1

121F ........... JWJ8HHBLK-121F…..Motor Fan (not shown) .................................................. ........................................ 1

121J ........... JWJ8HHBLK-121J ....... Junction Box (not shown) ............................................. ........................................ 1

121R .......... JWJ8HHBLK-121R. ..... Running Capacitor (not shown).................................... 35μF, 450V AC ............... 1

122 ............. ** .................................. Socket Head Cap Screw .............................................. M8x30 ............................. 4

123 ............. JWJ8HHBLK-123 ........ Rubber Pad .................................................................. ........................................ 1

124 ............. JWJ8HHBLK-124 ........ JET Logo with Adhesive ............................................... 8x15T .............................. 1

125 ............. JWJ8HHBLK-125 ........ JJ8 Model Logo with Adhesive .................................... ........................................ 1

126 ............. JWJ8HHBLK-126 ........ Warning Label 01, JWJ-8HH-BLK ................................ ........................................ 1

127 ............. JWJ8HHBLK-

127 ........ Warning Label 02, JWJ-8HH-BLK ................................ ........................................ 1

128 ............. JWJ8HHBLK-128 ........ Black Sticker for Stand, JWJ-8HH-BLK ....................... ........................................ 1

201 ............. ** .................................. Socket Head Cap Screw .............................................. M6x10 ............................. 1

202 ............. JWJ8HHBLK-202 ........ Large Washer ............................................................... 6mm ................................ 1

203 ............. JWJ8HHBLK-203 ........ Key A4X12 ................................................................... A 4X12 ............................ 1

204 ............. JWJ8HHBLK-204 ........ Handwheel ................................................................... ........................................ 1

205 ............. JWJ8HHBLK-205 ........ Wedge Iron ................................................................... ........................................ 2

206 ............ ** ............................... Outfeed Table (PTFE).................................................... ............................... 1

207 ............. ** .................................. Socket Set Screw ......................................................... M6x6 ............................... 2

209A .......... JWJ8HHBLK-209A ...... Screw Shaft Seat Assembly ......................................... ........................................ 1

210 ............. ** .................................. Flat Washer .................................................................. 8 mm ............................... 2

211 ............. ** .................................. Lock Washer ................................................................ 8 mm ............................... 2

212 ............. ** .................................. Socket Head Cap Screw .............................................. M8x30 ............................. 2

213 ............. ** .................................. Flat Washer .................................................................. 12 mm ............................. 2

216 ............. ** .................................. Hex Nut ........................................................................ M10 ................................. 2

217 ............. ** .................................. Lock Washer ................................................................ 10mm .............................. 2

218 ............ ** ............................... Table Seat ............................................................... ...................................... 1

219 ............. ** .................................. Socket Set Screw ......................................................... M8x30 ............................. 6

220 ............. ** .................................. Socket Flat Head Screw ............................................... M8 ................................... 8

221 ............. JWJ8HHBLK-221 ........ Locking Handle ............................................................ ........................................ 1

222A .......... JWJ8HHBLK-222A ...... Lifting Block Assembly ................................................. ........................................ 1

223 ............. JWJ8HHBLK-223 ........ E-Ring ......................................................................... 9 mm ............................... 4

224A .......... JWJ8HHBLK-224A ...... Pointer Assembly ......................................................... ........................................ 1

225 ............. ** .................................. Pan Head Machine Screw ............................................ M4x8 ............................... 1

227 ............ ** ............................... Infeed Table (PTFE) ................................................ ...................................... 1

235 ............. JWJ8HHBLK-235 ........ Driving Belt ................................................................... O-880 .............................. 2

236 ............. JWJ8HHBLK-236 ........ Thin Hex Nut ................................................................ M8 ................................... 1

237 ............. ** .................................. Socket Head Cap Screw .............................................. M8x20 ............................. 1

238 ............. JWJ8HHBLK-238 ........ Two Ends Bolt .............................................................. ........................................ 2

239A .......... JWJ8HHBLK-239A ...... Setting Block Assembly ................................................ ........................................ 1

240 ............. ** .................................. Socket Head Cap Screw .............................................. M8x25 ............................. 2

241 ............. ** .................................. Socket Set Screw ......................................................... M8x20 ............................. 1

243A .......... JWJ8HHBLK-243A ...... Belt Cover A Assembly ................................................ ........................................ 1
