91
Oil the lower shaft supporter (bottom)
1.
Lay the machine as shown.
Remove the maintenance cover on the bottom side of
the machine with a screwdriver.
(1)
M
aintenance cover
2.
Oil the upper shaft supporter (top side)
1.
Remove the cover and the cap on the top side of the
machine.
(1) Cover
(2) Cap
2.
Oil the arrow points (felt) as indicated in the
illustration.
1.
2.
Oil the arrow point (felt) as indicated in the illustration.
(2) Felt
(3) Shaft
After oiling, attach the maintenance cover, follow the
procedure
1.
to
2.
in reverse.
1.
2.
NOTE:
If the oil does not reach the arrow point, soak a cotton
swab in oil and apply it to the machine.
NOTE:
Do not tilt the machine for about 30 minutes after
oiling.
(1)
(3)
(2)
(1)
(2)
