23
Selecting embroidery thread
Select the thread from the “Thread Selection” before
threading the machine (refer to page 83).
Press the next page key to show the next page.
(1) Next page key
(1)
Bobbin holder for embroidery (high tension)
Replace the standard bobbin holder (part number
867513002) with the special bobbin holder (high tension,
part number 867513208) when using bobbin threads
other than Janome bobbin thread for embroidery.
Either part number (867513002 or 867513208) is
indicated inside the bobbin holder.
(1) Part number indicated here
1.
Remove the needle, embroidery foot and needle
plate (refer to the pages 13, 12, 86).
Take out the standard bobbin holder.
(2) Standard bobbin holder
2.
Insert the special bobbin holder into the hook race.
Make sure to match the knob of the bobbin holder
with the stopper on the machine.
Attach the needle plate, embroidery foot and needle.
(3) Knob
(4) Stopper
(5) Special bobbin holder for embroidery
(high tension)
CAUTION:
Always make sure to press the lockout key to lockout
the machine or turn the power switch OFF before
replacing the bobbin holder.
NOTE:
Use the standard bobbin holder when sewing designs
that use the same thread for the bobbin as the needle
thread.
NOTE:
Use Janome synthetic #90 for bobbin thread.
1.
2.
(2)
(4)
(3)
(5)
(1)
