14
Setting the spool of thread
Lift up the spool pin. Place the spool of thread on the
spool pin.
Attach the spool holder (large), and press it rmly against
the spool of thread.
(1)
S
pool holder (large)
Winding the Bobbin
Removing the Bobbin
Slide the hook cover release button to the right, and
remove the hook cover plate.
Lift out the bobbin from the bobbin holder.
(1)
H
ook cover release button
(2)
H
ook cover plate
(3)
B
obbin
(3)
(1)
(2)
(3)
Extra spool pin
Use the extra spool pin when you need to wind a bobbin
without unthreading the machine while working on a
sewing project (refer to page 15).
Insert the extra spool pin into the hole as shown.
Place a spool of thread on the extra spool pin and x the
spool with the spool holder.
(1) Extra spool pin
(2) Hole for extra spool pin
(3) Spool holder (large)
(2)
(3)
(1)
NOTE:
•
U
se “J” plastic bobbins (4) for the horizontal hook.
Using other bobbins, such as pre-wound paper
bobbins, may cause stitching problems and/or
damage to the bobbin holder.
•
D
o not use the easy bobbin or metal bobbins.
NOTE:
Remove the extra spool pin when covering the
machine with the soft cover.
NOTE:
• If you use a slippery thread such as monolament
transparent thread, elastic thread or metallic thread,
put a net on the spool of thread to prevent the thread
from slipping off the spool and jamming around the
spool pin.
If the net is too long for the spool, fold the net and
place it on the spool.
• A spool net is not included with this machine.
(3)
S
pool net
(4)
Use the spool holder (small) to hold narrow or small
spools of thread.
(2) Spool holder (small)
(1)
(2)
