27
Replacing the Needle
1.
Raise the needle by pressing the needle up/down
button.
Press the lockout key to lockout the machine.
Lower the presser foot lifter.
(1) Needle up/down button
(2) Lockout key
(3) Presser foot lifter
2.
Loosen the needle clamp screw by turning it
counterclockwise.
Remove the needle from the clamp.
(4) Needle clamp screw
3.
Insert a new needle into the needle clamp with the
at side of the needle to the rear.
When inserting the needle into the needle clamp,
push it up against the stopper pin and tighten the
needle clamp screw rmly with a screwdriver.
Press the lockout key to unlock the machine.
(5) Flat side
(6) Stopper pin
3.2.
1.
(1)
(2)
(5)
(6)
(7)
CAUTION:
Always make sure to press the lockout key to lockout
the machine or turn the power switch OFF before
replacing the needle.
CAUTION:
Be sure to tighten the needle clamp screw rmly with
a screwdriver when attaching a needle to the machine,
otherwise the needle may break or cause malfunction.
(4)
(3)
To check needle straightness, place the at side of the
needle onto something at (a needle plate, glass, etc.).
The gap between the needle and the at surface should be
consistent.
(7) Gap
Never use a blunt needle.
