9
Setting Spool Pins
The spool pins are used for holding the spool of
thread in order to feed thread to the machine.
To use, pull up the spool pin. Push down for
storage.
Removing or Inserting the Bobbin Case
z Remove the extension table by pulling it to the
left.
Open the hook cover.
q Hook cover
x Raise the needle by turning the handwheel
toward you. Take out the bobbin case by
holding the latch.
w Latch
c When inserting the bobbin case, place the
horn into the recess of the hook race.
e Horn
NOTE: :
When using thread which has tendency to
tangle around spool pin, thread through the
hole of spool pin as shown. The hole should
face the thread spool.
q Upper thread
w Hole
e Tangle
q
e
q
w
q
w
e
z
x
c
