07610-004-66-53-F
29
TROUBLESHOOTING
TROUBLESHOOTING
OBSERVATION POSSIBLE CAUSE REMEDY
Rinse water is heated,
but not reaching
required temperature.
1. Faulty rinse heater.
2. Faulty temperature probe (T2- rinse
injector, T3-rinse tank).
3. I/O module is faulty.
1. Verify element has very low resistance (< 20 Ω) across
terminals. If high resistance or open, replace the heater.
2. Measure probe’s resistance with ohmmeter, which should be
~10 kΩ at 77 °F. Replace probe if much dierent than this
value.
Reference: resistances at 70 °F & 85 °F are ~11.9 kΩ & 7.4
kΩ, respectively.
3. Verify module is receiving power (green LEDs are on); if so,
replace module.
Low-water rinse.
1. Rinse pump not performing properly.
2. Clogged or obstructed rinse arms.
1. Perform PSI check (see Preventative Maintenance page).
2. Remove and clean rinse arms.
Wash water is not
reaching required
temperature.
1. Faulty wash heater.
2. Faulty temperature probe (T1).
3. I/O module is faulty.
1. Verify element has very low resistance (< 20 Ω) across
terminals. If high resistance or open, replace heater.
2. Measure probe’s resistance with ohmmeter, which should be
~10 kΩ at 77 °F. Replace probe if much dierent than this
value.
Reference: resistances at 70 °F & 85 °F are ~11.9 kΩ & 7.4
kΩ, respectively.
3. Verify module is receiving power (green LEDs are on); if so,
replace module.
Door will not close
completely.
1. Improper spring tension.
2. Obstruction in door slide channel.
1. Adjust spring tension to desired stiness by loosening (not
removing) spring bolt nuts near bottom of machine, and
adjusting tension. Tighten nuts back when done.
2. Remove obstruction.
Water leaks at wash
pump.
1. Wash pump seal defective.
2. Loose hoses (hose clamps) on wash
pump.
1. Replace seal.
2. Tighten hose clamps.
Will not rinse during
cycle.
1. Defective rinse solenoid.
2. Timer module is faulty.
1. Repair or replace rinse solenoid.
2. Verify module is receiving power (green LEDs are on); if so,
replace module.
Dishes are not coming
clean.
1. Machine temperatures are below
minimum requirements.
2. No detergent or too much detergent.
3. Solid dispenser canister is empty.
1. Verify incoming water, rinse water, and wash water match
required temperatures as listed on the machine data plate.
2. Adjust detergent concentration as required for amount of water
held by the machine.
3. Replace canister.
WARNING! Inspection, testing, and repair of electrical equipment should only be performed by a
qualied service technician. Many tests require the machine to have power to it and live electrical
components be exposed. USE EXTREME CAUTION WHEN TESTING THE MACHINE.
!
WARNING
