07610-004-66-53-F
28
OBSERVATION POSSIBLE CAUSE REMEDY
Digital display does not
illuminate after power
button is pressed.
1. Service breaker tripped.
2. Machine not connected to power
source.
3. Faulty power source.
1. Reset breaker. If it trips again, contact an electrician to verify
amp draw of the machine.
2. Verify the machine has been properly connected to power
source.
3. Verify wiring to breaker switch.
Machine does not ll when
powered on (door must be
closed.)
1. Tank already full.
2. Faulty rinse solenoid valve.
3. Faulty door switch.
4. Faulty oat switch.
1. N/A
2. Repair or replace valve as required.
3. Verify wiring of switch; if correct, replace switch.
4. Verify wiring of both oat switches; if correct, replace switch.
Machine will not begin
wash cycle upon closing
door.
1. Wash motor faulty/damaged.
2. Wash motor contactor faulty.
3. Timer module is faulty.
4. I/O module is faulty.
1. Verify wash motor is receiving power; if so, replace motor.
2. Verify contactor energizes; if so, with contactor energized,
verify continuity across poles; if contacts are open, replace
contactor.
3. Verify module is receiving power (red LED is on); if so, replace
module.
4. Verify module is receiving power (green LEDs are on); if so,
replace module.
Machine continuously
washes.
1. Machine is in Delime mode,
which will be indicated on display.
2. Timer module is faulty.
1. Turn o Delime mode by pressing delime button.
2. Verify module is receiving power (green LEDs are on); if so,
replace module.
Wash or rinse heater does
not work.
1. Faulty heater element.
2. Faulty heater contactor.
3. Faulty temperature probe (T1-
wash tank, T3-rinse tank).
4. High-limit thermostat is tripped.
1. Verify element has very low resistance (< 20 Ω) across
terminals. If high resistance or open, replace heater.
2. Verify contactor energizes; if so, with contactor energized,
verify continuity across poles; if contacts are open, replace
contactor.
3. Measure probe’s resistance with ohmmeter, which should be
~10 kΩ at 77 °F. Replace probe if much dierent than this
value.
Reference: resistances at 70 °F & 85 °F are ~11.9 kΩ & 7.4
kΩ, respectively.
4. Contact a qualied service agency.
Machine lls slowly.
1. Y-strainer is clogged 1. Clean Y-strainer.
WARNING! Inspection, testing, and repair of electrical equipment should only be performed by a
qualied service technician. Many tests require the machine to have power to it and live electrical
components be exposed. USE EXTREME CAUTION WHEN TESTING THE MACHINE.
!
WARNING
TROUBLESHOOTING
TROUBLESHOOTING
