INSTRUCTIONS
INSTALLATION
PLUMBING
CHECK
Read the Plumbing section on the previous page before proceeding.
Install water supply line to the machine. Hose or pipe must be 1/2" ID minimum. Using
smaller hose or pipe will aect machine performance and related issues are not the
responsibility of the manufacturer.
Install a water shut-o valve in the water line between the main supply and the
machine to allow access for service.
If water hardness tests greater than 3 GPG, install the Scaltrol Water Treatment
system (see the Plumbing Options page) into the water line before the machine’s
incoming water connection point. If water hardness tests at 3 GPG or less, install the
water supply line directly to the machine’s incoming water connection point.
DynaStar and HH-E models are equipped with a rinse pump, so a PRV is not required
unless ow pressure is over 65 PSI. Flow pressure under 15 PSI could aect ll/start-
up time. DynaStar NB and HH-E NB are not equipped with a rinse pump, so a PRV
is recommended (see the Plumbing Options page) and ow pressure is 10 ± 2 PSI.
The manufacturer recommends the installation of a water hammer arrestor in the
incoming water line and oers these devices as options. See the Plumbing Options
page. This prevents line hammer/hydraulic shock—induced by the solenoid valve as
it operates—from causing damage to the equipment.
1. Slowly turn on water supply to the machine after incoming ll line and drain line
have been installed.
2. Check for any leaks and repair as required.
WATER SUPPLY
CONNECTION
!
CAUTION
NOTICE
A water hardness test
must be performed!
Shut-off
Valve
Adapter AdapterScaltrol Machine
Water Line
Facility
Water Line
* *
*Adapters needed will vary.
CAUTION! Repair all leaks
before operating machine!
!
CAUTION
CAUTION! 1/2" ID MIN
water line must be used!
