07610-003-92-84-P
8
INSTRUCTIONS
INSTALLATION
Before installing the unit, check the packaging and machine for damage. If the
packaging is damaged, the machine might also be damaged. If there is damage to
both the packaging and machine, do not throw away the packaging. The dishmachine
has been inspected and packed at the factory and is expected to arrive to you in new,
undamaged condition. However, rough handling by carriers or others might result in
damage to the unit while in transit. If so, do not return the unit to the manufacturer;
instead, contact the carrier and ask them to send a representative to the site to inspect
the damage and complete an inspection report. You must contact the carrier and the
dealer that sold you the unit within 48 hours of receiving the machine.
While removing the machine from the packaging, ensure that there are no missing
parts. If an item is missing, contact the manufacturer immediately.
The dishmachine must be level in its operating location to prevent damage to the
machine during operation and to ensure the best results. The unit comes with four
adjustable bullet feet, which can be turned using a pair of channel locks (or by hand if
the unit can be raised safely). Ensure that the unit is level from side-to-side and front-to-
back before making any connections.
Plumbing connections must comply with all applicable local, state, and national
plumbing codes. The plumber is responsible for ensuring that the incoming water line
is thoroughly ushed before connecting it to any component of the dishmachine. It is
very important to remove all foreign debris from the water line that might potentially get
trapped in the valves or cause an obstruction. Any valves that are fouled as a result of
foreign matter left in the water line—and any expenses resulting from this fouling—are
not the responsibility of the manufacturer.
A water hardness test must be performed. A hardness test kit can be found on the
warning tag that is attached to the incoming plumbing connection on the back of the
machine. If water hardness is higher than 3 GPG, install a water softener or install
the optional HTS-11 (scale prevention and corrosion control). Please contact the
manufacturer to purchase the HTS-11.
If water hardness is higher than 3 GPG and a water softener is not being used, install
the HTS-11 into the water line before the dishmachine’s incoming water connection
point using copper pipe. Observe proper inlet/outlet water directions. Flow directions
are molded into the top of the head. It is recommended that a water shut-off valve
be installed before installing the HTS-11 to allow access for service. Plumb from the
HTS-11 outlet to the incoming water connection point using copper pipe (or order the
exible hose kit offered by manufacturer).
INSPECTION
LEVELING
UNPACKING
PLUMBING
Do not throw away the
container if damage is
evident!
The plumber MUST ush
the incoming water line!
WATER SUPPLY
CONNECTION:
WATER HARDNESS
HIGHER THAN
3 GPG
A water hardness test
must be performed.
