06
CHARGING YOUR JACKERY EXPLORER 3000
Green energy first: We advocate to use the green energy first. This product supports two modes of
charging at the same time: solar charging and AC wall charging.
When AC wall charging and solar charging are turned on at the same time, the product will give
priority to solar charging and both methods will be used to charge the battery at the maximum
permissible power.
The Jackery Explorer 3000 has two low-PV input ports, each one supports direct connection of
one 500W or three 200W solar panels at most. If one low-PV input port needs to connect two or
more solar panels simultaneously, please refer to the figure below for charging through the solar
panel connector (sold separately, not included as standard).
CHARGING VIA SOLAR PANELS
CHARGING VIA AC WALL OUTLET
Connect the AC charge cable to the AC input
port of the power station and plug it into the
wall outlet.
Jackery Explorer 3000
AC Charging Cable
US
Jackery Explorer 3000
Jackery Explorer 3000
SolarSaga 200 × 2SolarSaga 200 × 2
*When the two inputs are used at the same time, please make sure to use the same type of solar panel
and the number of solar panels in the two inputs must be the same to avoid damage or charging
problems of the equipment due to inconsistent voltages of the two channels.
Fully charge the device before its first use.
Note: 1. The recommended charging temperature for the product is between 0°C to 45°C (32°F to 113°F),
and the discharging temperature is between -15°C to 45°C (5°F to 113°F). Operating the product outside
this temperature range may restrict its charging and discharging capabilities, or even render it unable
to charge or discharge.
2. The charging power and battery capacity of the product may vary due to temperature fluctuations.
SolarSaga 500 X × 2
