CAN@net II - Manual, V2.0
Configuration
15
4.1.2 Usage
When the configuration tool is started, the network is scanned for CAN@net II
devices. If a device is connected to the network later, there are two possibilities
for detecting the new device:
• activating the function “Autoscan”, so that the tool scans the network every 3
seconds, or
• pushing the “Rescan” button for a single network scan.
For configuring the network parameters of a CAN@net II, the desired device
has to be chosen from the “Device List”. After that, the “Configure” button has
to be pushed. This is only possible if the device is not connected to another
application (Connection State: Not Connected).
In the configuration dialog, the DHCP mode can be activated or deactivated.
The IP address, the subnet mask and the gateway can only be set in the non-
DCHP mode. In addition, the hostname and the password can be set.
When “OK” is clicked, the parameters are written to the CAN@net II. For
successful operation, the password has to be entered. The configuration can be
stopped with “Cancel”.
The default settings of the network parameters are shown in the appendix.
4.2 Resetting the Network Parameters
The default settings of the network parameters can be reloaded using the DIP
switch.
The following steps are necessary:
(1) Ensure that you are electro-statically discharged.
(2) Switch off the CAN@net II and unplug the power connector.
(3) Separate the top housing (incl. printed board) from the bottom housing. For
this, the two package locks have to be pressed in slightly.
(4) Switch number 1 of the DIP switch to “ON”.
(5) Put the printed board back in the bottom housing. Pay attention to the ESD
plastic film, because it has to be assembled.
(6) Connect the CAN@net II to the power supply. A green and red running light
has to be displayed by the LEDs PWR, CPU, ETH and CAN.
(7) Disconnect the CAN@net II from the power supply.
(8) Remove the PCB from the bottom housing in a similar way to the steps
described above.
(9) Switch number 1 of the DIP switch back to “Off”.
(10) Put the printed board including the ESD plastic film back in the bottom
housing. Ensure that the package lock is active again.
