15
9 Power LED Power LED lights blue to indicate that the IOGEAR Secure KVM Switch is powered
on
10 USB Console Ports
Wired USB keyboard and mouse are connected into these ports. The USB console
keyboard port (lower port) and mouse port (upper port) are only compatible with
standard wired USB keyboards/mice
Note:
1. The console USB keyboard and mouse ports are interchangeable. User
can connect a keyboard to the mouse port and vice versa. However, for
optimal operation, it is recommended that the USB keyboard connected
to the console’s USB keyboard port and the USB mouse connected to the
console’s USB mouse port
2. For security purposes, IOGEAR Secure KVM Switch series do not support
wireless keyboards and mice. Do not attempt to connect a wireless key-
board and mouse to the switch in any case.
3. Non-standard keyboards/mice with integrated USB hubs and/or other
USB-integrated devices may not be fully supported due to the strict security
standards and policy for IOGEAR Secure KVM Switch. If supported, only
basic (HID) keyboard/mouse operations will function
4. Multimedia keys on the keyboard will not function due to security policy
5. Num Lock, Caps Lock, and Scroll Lock LED on keyboards will not function
due to security policy.
11 PS/2 Console Ports Wired PS/2 keyboard and mouse are connected into these ports.
(PS/2 Mouse port: Green; PS/2 Keyboard port: Purple)
12 Video LED(s)
Video LED lights green when the video connection is established.
Video LED ashes when a non-qualied monitor is connected.
Note:
With the Dual View (dual monitor) models, each console video connection has one
Video LED
13 Console Monitor Port(s)
Console monitor’s cables are connected into these ports
Note:
IOGEAR Secure KVM Switch Dual View models has two console monitor ports
14 KVM Port Section Connect IOGEAR proprietary KVM cables from the computers into these ports
15 KVM Audio Ports
Connect audio cable from the connected computers into these ports
Note:
Only speaker connections are allowed. The use of analog microphones or line-in
audio devices is strictly prohibited
16 KVM USB Ports Connect the USB cable from the keyboard and mouse into these ports
17 USB Smart Card / CAC
(Common Access Card)
Reader Port
Connect the USB cable from the connected USB Smart Card / CAC reader into
these ports
18 Power Switch This is a standard rocker switch that powers the IOGEAR Secure KVM Switch off
and on
19 Power Socket Connect the included AC power cord into this socket
Overview
