14
Overview
No. Component Description
1 Port Selection Pushbuttons Pressing a Port Selection Pushbutton brings together the Keyboard, Mouse, Video,
Audio, and CAC reader focus to the computer attached to the corresponding port
2 Port and CAC LEDs
The Port/CAC LEDs located on front panel are to indicate Port/CAC reader selec-
tion or connection status.
Port LEDs (Bottom row; Orange LEDs)
❒ Online – Port LED lights dim orange to indicate that the computer attached
to its corresponding port is connected and powered on
❒ Selected – Port LED lights bright orange to indicate that the computer
attached to its corresponding port has the KVM focus
CAC LEDs (Upper row; Green LEDs)
❒ Online – CAC LED lights dim green to indicate that the computer attached
to its corresponding port has a USB CAC reader cable connection up and
running, and the CAC function is enabled
❒ Selected – CAC LED lights bright green to indicate that the CAC function is
enabled and the computer attached to its corresponding port has the CAC
focus
❒ None – No lights indicate that the cable is not connected or the CAC function
has been disabled
❒ Warning – CAC LED Flashes to indicate that a non-qualied USB Smart
Card/ CAC reader is connected when the corresponding port has the focus
Note:
1. CAC function of each port can be enabled or disabled by pressing the port
selection pushbutton for more than 3 seconds (this is a toggle feature).
Please refer to the Operation section of this user manual for more informa-
tion.
2. All front panel LEDs (except for Power LED) will ash continuously when
a chassis intrusion or self-test failure is detected. See Chassis Intrusion
Detection section for further details
3. Port and CAC LEDs also indicate the status of the Secure KVM self-test.
See Operation section for further details
3 Reset Button
Press the Reset Button to reset IOGEAR Secure KVM Switch
Note:
1. When the Reset Button is pressed for more than 5 seconds, the Keyboard/
Mouse buffer will be purged and KVM switch will reboot and perform a self-
test. After a successful self-test, port focus will be switched to Port 1, and
CAC function of each port will be set to factory default (enabled).
2. If the Secure KVM fails to generate video on the monitor after a reset,
please power off the installation, check the cables, and follow the instruc-
tions in this manual to power on the installation
4 Audio Ports
Connect cables from your speakers to these audio ports
Note:
Only standard analog speaker connections are allowed. The use of analog micro-
phones or line-in audio devices is strictly prohibited
5
USB Smart Card/CAC
Reader Port
Only qualied USB authentication devices (e.g., standard smart card and CAC
reader) can be connected to this port.
Note:
USB Authentication device lter is congurable by authorized administrators for
trusted authentication devices (e.g. USB token, USB Biometric reader). Please
refer to Administrator’s Guide for details.
6 Num Lock LED
Num Lock LED lights green to indicate that the Num Lock function has been turned
on.
Note:
Num Lock LED on keyboard will be disabled due to security requirement
7 Caps Lock LED
Caps Lock LED lights green to indicate that the Caps Lock function has been
turned on
Note:
Caps Lock LED on keyboard will be disabled due to security requirement
8 Scroll Lock LED
Scroll Lock LED lights green to indicate that the Scroll Lock function has been
turned on.
Note:
Scroll Lock LED on keyboard will be disabled due to security requirement
