BREAKDOWN CODES
The breakdown codes are shown on the displays on the control panel.
Breakdown code Cause Solution
E1, E2, E7 The temperature sensor is defective. Contact the Inventum service department.
E3, E4 The glass plate sensor is defective. Contact the Inventum service department.
EU
The connection between the circuit boards
is defective.
Contact the Inventum service department.
EL, EH The voltage is too low or too high. Have your connection checked by an electrician.
C1, C2
The temperature of the glass plate sensor
is too high.
Allow the glass plate to cool down and then switch
on the induction hob again.
F5 The fan is defective. Contact the Inventum service department.
EF Overflow error
Check if there is (cooking) water on the hob.
If so, clean and dry the hob.
ENERGY CONSUMPTION
Symbol Type Value
Energy consumption for the hob calculated per kg EC electric hob Hob 182,3 Wh/kg
Energy consumption per cooking area calculated per kg EC electric cooking Cooking area left 191,5 Wh/kg
Energy consumption per cooking zone calculated per kg EC electric cooking Cooking zone center 172,9 Wh/kg
Energy consumption per cooking zone calculated per kg EC electric cooking Cooking zone rear right 183,8 Wh/kg
Energy consumption per cooking zone calculated per kg EC electric cooking Cooking zone front right 181,0 Wh/kg
37 • English
