Section 6:
Checking Out and Verifying the System
After you have completed installation and programming, make sure the
system is working OK by completing the procedures listed below. Later on,
if problems develop in using the system, going over these same procedures
will help you troubleshoot the problem.
This section will help you with procedures to:
• Verify that display on the PE953 Hand-Held Controller is operational and
showing the correct time of day.
• Verify that the PE653 Device is operational and working.
• Verify that the PE953 Hand-Held Controller is communicating with the
PE653 Device
• Verify that the PE953 Hand-Held Controller will communicate with the
PE653 Device from everywhere on your property.
• Verify that the (POOL/SPA switch on the PE953 Hand-Held Controller
activates the Motorized Valve Actuators (if installed)
• Verify that the Heater is responding to commands from the PE953 Hand-
Held Controller.
What to do If it doesn’t work Reference/Procedure
Verify that
display on the
PE953 Hand-
Held Controller
is operational
and showing
the correct time
of day.
Press and release
any button on
the Hand-Held
Controller to wake it
from sleep.
Refer to Section 1: Programming the PE953
Hand-Held Controller on page 9.
Check the batteries 1. Use a small Phillips screwdriver to remove
the three screws on the back of the unit, as
indicated. (See page 24.)
2. Verify that the batteries are good or replace
them with three new AA batteries.
NOTE: Be sure to re-install the gasket
correctly to maintain the watertight seal.
Set the correct time
of day.
1. Press and hold the P/S button until the
screendisplaysSETTIMEunderthetime
display.
2. Use the Up/Down Arrow buttons to set the
correct time.
3. Press the ENTER Key to return to the main
PE653 main screen.
Refer to page 15 for additional help.
ContactIntermaticsupportservices.
38 I-Wave PE953 Installation Guide
Copyright © 2011 Intermatic, Inc.
What to do If it doesn’t work Reference/Procedure
Verify that the
PE653 Device is
operational and
working.
Verify that power
is ON to the PE653
Device.
1. Turn the main circuit breaker that feeds the
panel to the ON position.
2. Use a voltmeter to verify that voltage is
present at terminals 1 & 2.
Verify the Voltage
Selector Switch is in
the proper position.
Voltage Selection Switch should be in the 120V
or 240V position corresponding to the voltage
reading observed in Step 2 above.
Verify that the F1 Fuse
is not blown.
1. Turn OFF the power to the PE653 Device.
2. Remove the fuse and test with an ohmmeter
or fuse tester.
3. Replace the fuse if good or install a new fuse.
4. Turn the power to the PE653 Device ON.
Verify that each circuit
is operational.
1. Press the ON switch for Circuit #1.
2. Verify that the Load ON indicator for Circuit
#1 is ON.
3. Press the ON switch for Circuit #2.
4. Verify that the Load ON indicator for Circuit
#2 is ON.
5. Press the ON switch for Circuit #3.
6. Verify that the Load ON indicator for Circuit
#3 is ON.
7. Press the ON switch for Circuit #4.
8. Verify that the Load ON indicator for Circuit
#4 is ON.
9. Press the ON switch for Circuit #5 verify that
the Load ON indicator for Circuit #5 is ON.
Turn OFF all Circuits.
Verify that the
electrical wiring for
each load is correct.
Refer to the appropriate wiring diagram in
Section3oftheInstallationandUserGuide,
starting on page 13.
What to do If it doesn’t work Reference/Procedure
Verify that the
PE953 Hand-
Held Controller
is communicating
with the PE653
Device
Test communications
between the PE953
and the PE653.
1. Press and release any button on the Hand-
Held Controller to wake it from sleep.
2. Press the number 1 switch on the PE953.
3. Verify that Circuit #1 turns ON.
4. Press the number 1 switch again to turn OFF.
5. Press the number 2 switch on the PE953.
6. Verify that Circuit #2 turns ON.
7. Press the number 2 switch again to turn OFF.
8. Repeat for all 5 circuits.
Review Section 4:
Programming the
PE953 Hand-Held
Controller starting on
page 41.
Refer to page 43: Linking the Hand-Held
Controller to the PE653 Receiving Device.
