Two: Everyday use of the PE953 Hand-Held Controller 21
Providing a brighter solution.™
Controlling the PE653 Receiving Device
TocontrolsettingsconguredwiththePE653ReceivingDevice
1. Press and release any button on the Hand-Held
Controller to wake it from sleep. (The unit goes to
sleep to conserve battery life when it has been idle
for 60 seconds.)
2. Press the <ENTER> button until you see the PE653
screen, as shown.
Operating Programmed Functions
Dependingonhowyouhavewiredthesystem,thevefunctionbuttonson
theHand-HeldControlleroperatesthevecircuitsinthePE653Receiving
Device.
When you press any of these buttons, the appropriate circuit toggles ON or
OFF.Inaddition,whenthecircuitisON,theHand-HeldController’sdisplay
shows the circuit number along the top of the screen.
Changing between Pool and Spa
The Valve Actuator (PE24VA) that you have installed in the system directs
water either to the pool or the spa. To use the Hand-Held Controller to
control this valve:
1. Press and release any button on the Hand-Held
Controller to wake it from sleep. The screen display
should look generally like the example on the right.
Ifnot,pressthe<ENTER> button until you see this
screen.
NOTE: The lower-right area of Hand-Held Controller Screen displays the
current mode for the system — in this example it is POOL. The screen will
indicate:
POOL if the valve actuator is in pool mode
SPA if in spa mode
The number following the word POOL or SPA is the current water
temperature for the water in whichever mode is being displayed.
3. Press and release the <P/S> button. The system toggles between POOL
and SPA mode. :
4. Intheexampleattheright,themodeisnow
changed to SPA, and the temperature shown is the
water temperature of the SPA.
NOTE: The large numeric display shown on the Hand-
Held Controller Screen shows the current time of
day.
