12.2 Notification codes
In addition to fault codes, the control unit can also display notifications. Notifications are displayed if an anomaly occurs
somewhere in the system that does not aect the vital functioning of the system. Notifications disappear if the system can
fix the anomaly. Intergas Heating must be consulted if a notification returns repeatedly.
When using a digital type OpenTherm room thermostat notification codes from either the heat pump or the boiler can be
displayed on its display screen, otherwise they can be viewed via the WiFi control screen.
Non compatible OpenTherm room stats will display F050 = heat pump error or F051 = CH-boiler error
The following notifications are used:
Notification Description Possible cause/solution
n000
Parameter settings outside
range
► Check the settings.
n001
System pressure too low,
parameter P020
► Check for leaks
► The system water requires refilling or topping up.
n008
XTP error heat pump (ODU) ► Consult Intergas Heating Ltd.
n011
Communication with the
outdoor unit has been lost
or the outdoor unit has an
internal .
► Access the WiFi control screen for additional information
► Check the wiring between the indoor unit and outdoor unit for breakages/short
circuit.
► Check the connections in the outdoor unit.
n013
Condenser temperature
too high: heating pump
disengaged.
► Potentially insuicient flow.
n014
Thermostat not connected. ► Connect the Comfort Touch thermostat; see §8.8.5.
n015
Crankcase heater function
► Possible loose connection to the outdoor unit
► Faulty resistance element.
n016
Abnormal Delta-T between
the flow and return
temperature values
► Sensors T03 and T04 connected or mounted incorrectly.
► Check the system flow.
n018
Problem with memory. ► Consult Intergas Heating Ltd.
n019
Fault memory module
► Check the wiring.
► Replace the memory module.
n021
No flow in the CH circuit for
at least 30 seconds.
► Venting program (max. 15 minutes) is started. Other system functions are
blocked and resumed aer the program has completed.
► Pump turns o for 60 seconds.
► Pump runs at maximum capacity.
► If suicient flow is regained again for 30 seconds, the program will stop and the
notification code will clear.
n022
Problem with automatic
flow rate control
► Probably air in the system, vent.
n023
System flow too low during
commissioning
► Check the CH-circuit for restrictions, debris, air or isolation valves closed.
n039
Problem with external flow
temperature sensor T43
► Check the position and connection of the sensor on the flow pipework.
► Check wiring. Replace if necessary.
n040
Problem with external
outdoor sensor T42
► Check wiring. Replace if necessary.
n041
Problem with refrigerant
liquid sensor.
► Check wiring. Replace if necessary.
n042
Problem with refrigerant
gas sensor.
► Check wiring. Replace if necessary.
n051
Boiler locked out of system ► Check for boiler malfunction.
