8.5 Setting up the outdoor unit
8.5.1 Points of attention for location
► The outdoor unit must be installed outdoors and on a
permenant load bearing surface that is suitable for the
weight of the unit.
► The unit must be mounted on anti-vibration feet (sold
separately).
► The unit location must be away from any external sources of
heat radiation or open flames.
► If possible place the outdoor unit in a shady location away
from direct sunlight.
► There must not be any obstacles/barriers in front of or near
the inlet and outlet side of the unit.
► Adverse weather conditions such as high wind, rain, snow
or even fallen leaves can eect the eiciency or operation
of the outdoor unit, so care should be taken when siting it,
open areas should be avoided if at all possible.
► During defrost mode it must be possible to drain
condensate water away from the unit base without it
freezing, the water should be piped to a suitable drain or
soakaway where it will not present a slip hazard from
freezing.
► When choosing a suitable location for the outdoor unit
please ensure that there is suicient clearance around the
unit housing; see §8.5.3. When doing so please ensure that
there is clear access to complete the installation and also
any further maintenance work (1).
► The side panel and any removed covers must be correctly
reinstalled aer the work has been completed. Incorrect
replacement can result in ingress from rain, spray water,
vermin etc. wich can lead to faults or irreparable damage to
the outdoor unit.
1
Intergas Heating Ltd are not responsible for damage caused by non-compliance with the safety requirements
and may decline to perform any maintenance or warranty work if there is a Health & Safety risk.
8.5.2 Transport
Leave the transportation packaging around the outdoor unit
in place for as long as possible to prevent external damage. If
it is necessary to hoist the unit, this must be done before the
transportation packaging is removed. An approved hoisting
strap suitable for the weight to be lied is required for hoisting.
To prevent damage, so protective material must be placed
between the straps and the corners of the outdoor unit. A hook
cannot be used for hoisting the indoor unit.
Please note: the gross weight of the outdoor unit is 46 kg.
IMPORTANT
► Do not touch the outdoor evaporator
fins with fingers, hands or objects.
This may damage the exchanger and/
or cause injury.
