Service Manual 5
Commercial Disposers
Electrical Requirements
The electrical wiring on disposers shipped from the factory are
not connected for a specic voltage. Refer to the Standard Motor
Connection Wiring Diagram attached to the inside of the disposer
terminal box cover for the correct voltage connections.
Standard disposer voltages are:
• 115/208/230 volts for single phase electrical power
• 208/230/460 volts for three phase electrical power
NOTE: All amp ratings denote amp draw during a grind load.
NOTE: The disposer motor phase and voltage must be the same
as the line or power supply.
ELECTRIC SHOCK! The disposer must be
permanently grounded.
DANGER
SS-50
1/2 H.P.
-26 115/208-230V, 60Hz, 1 Ph, 8.4/4.0/4.2 amps, UL
-27 208-230/460V, 60Hz, 3 Ph, 2.0/2.1/1.1 amps, UL
-28 115/208-230V, 60Hz, 1 Ph. 8.4/4.0/4.2 amps, CSA
-29 208-230/460V, 60Hz, 3 Ph, 2.0/2.1/1.1 amps, CSA
SS-75
3/4 HP
-27 115/208-230V, 60Hz, 1 Ph, 10.0/4.3/5.0 amps, UL
-28 208-230/460V, 60Hz, 3 Ph, 2.0/2.4/1.2 amps, UL
-29 115/208-230V, 60Hz, 1 Ph, 10.4/4.3/5.0 amps, CSA
-30 208-230/460V, 60Hz, 3 Ph, 2.0/2.4/1.2 amps, CSA
SS-100
1 H.P.
-28 115/208-230V, 60Hz, 1 Ph, 11.6/5.1/5.7 amps, UL
-29 208-230/460V, 60Hz, 3 Ph, 2.2/3.0/1.5 amps, UL
-30 115/208-230V, 60Hz, 3 Ph, 11.6/5.1/5.7 amps, CSA
-31 208-230/460V, 60Hz, 3 Ph, 2.2/3.0/1.5 amps, CSA
SS-125
1-1/4 H.P.
-25 115/208-230V, 60Hz, 1 Ph, 10.6/4.5/5.3 amps, UL
-26 208-230/460V, 60Hz, 3 Ph, 3.5/4.0/2.0 amps, UL
-27 15/208-230V, 60Hz, 1 Ph, 10.6/4.5/5.3 amps, CSA
-28 208-230/460V, 60Hz, 3 Ph, 3.5/4.0/2.0 amps, CSA
SS-150
1-1/2 H.P.
-34 115/208-230V, 60Hz, 1 Ph, 12.2/5.7/6.1, amps, UL
-36 208-230/460V, 60 Hz, 3 Ph, 3.2/4.6/2.3 amps, UL
-37 208-230/460V, 60 Hz, 3 Ph, 3.2/4.6/2.3 amps, CSA
-38 115/208-230V,, 60 Hz, 1 Ph, 12.2/5.7/6.1 amps, UL, short body
-39 208-230/460V, 60 Hz, 3 Ph, 3.2/4.6/2.3 amps, UL, short body
-35 115/208-230V, 60 Hz, 1 Ph, 12.2/5.7/6.1 amps, CSA
SS-200
2 H.P.
-27 115/208-230V, 60 Hz, 1 Ph, 17.4/7.7/8.7 amps, UL
-29 208-230/460V, 60 Hz, 3 Ph, 3.3/5.0/2.5 amps UL
-31 115/208-230V, 60 Hz, 1 Ph, 17.4/7.7/8.7 amps, UL, short body
-32 208-230/460V, 60 Hz, 3 Ph, 3.3/5.0/2.5 amps, UL, short body
-28 115/208-230, 60 Hz, 1 Ph, 17.4/7.7/8.7 amps, CSA
-30 208-240/460V 60Hz, 3 Ph, 3.3/5.0/2.5 amps, CSA
SS-300
3 H.P.
-25 208-230/460V, 60 Hz, 3 Ph, 6.0/7.4/3.7 amps, UL
-27 208-230/460V, 60 Hz, 3 Ph, 6.0/7.4/3.7 amps, UL, short body
-26 208-230/460V, 60 Hz, 3 Ph, 6.0/7.4/3.7 amps, CSA
SS-500
5 H.P.
-28 208-230/460V, 60 Hz, 3 Ph, 8.4/8.8/4.4 amps, UL
-30 208-230/460V, 60 Hz, 3 Ph, 8.4/8.8/4.4 amps, UL, short body
-29 208-230/460V, 60 Hz, 3 Ph, 8.4/8.8/4.4 amps, CSA
