20 21
CLIP-ON MODE QUICK MENU
Clip-on mode has abbreviated menu options. The clip-on quick
menu combines elements from the standard quick menu and the
main menu. Navigation of the clip-on mode quick menu is the same
as described in the previous section; only the menu options are
dierent:
• Bluetooth: Turn Bluetooth on or o.
• Image Contrast: Choose from levels 0–9.
• Image Sharpness: Choose from levels 0–9.
• Calibration: Set the non-uniformity correction (NUC) mode to
automatic (A), manual (M), or background (B).
• Microphone: Turn the microphone on or o.
• Status Auto Hide: Turn the status bar auto-hiding on or o.
• Unit: Set the unit of measure to meters or yards.
Navigating the Main Menu
From the home screen, long press the Rotary Encoder to enter the
main menu.
In all menu interfaces:
• Menu icons turn blue to indicate the current cursor position in
the top-level menu and all submenus.
• Use the Rotary Encoder to navigate the menu:
• Rotate to move left and right through the top-level menu and
submenu options, and to turn on or o toggle switches.
• Short press to enter the submenu. Short press again to
confirm submenu changes and return to the previous menu.
• Long press to save any changes and return to the home
screen.
In the quick menu:
• Menu icons turn blue to indicate the current cursor position in
the top-level menu and all submenus.
• Use the Rotary Encoder to navigate the quick menu:
• Rotate to move left and right through the top-level menu or
submenu options.
• Short press to enter the submenu. Short press again to
confirm submenu changes and return to the previous menu.
• Long press to save any changes and return to the home
screen.
• Short press the Power Button to return to the previous menu
without saving.
• When the cursor is in the top-level menu, the system will return
to the home screen, after 5 seconds of inactivity. The system
does not time out when the cursor is in a submenu.
• Upon exiting the main menu, the cursor location is stored for
a single working session (until the RICOHYBRID is turned o).
After restarting the RICOHYBRID and entering the menu, the
cursor position will be at the first menu item.
• The eight quick menu options are:
•
Quick Menu
Image Brightness: Choose from levels 0–9.
• Image Contrast: Choose from levels 0–9.
• Image Sharpness: Choose from levels 0–9.
• Calibration: Set the non-uniformity correction (NUC)
mode to automatic (A), manual (M), or background (B).
• Target Distance: Manually enter a target distance. Short
press the Rotary Encoder to move between digits and rotate
it to adjust the value of the selected digit.
• Reticle Type: Choose from type 1–7 (see Reticle Types
below) or the DIY reticle. Please note, the BDC reticle
overrides the Reticle Type selection.
• Reticle Color: Choose from white, black, red, green, or
blue.
• Reset Zeroing Distance: Select a zero distance
within the currently selected zeroing profile. Only the
zero distances in the selected profile will be available for
selection. The selected zero distance appears in the lower-
left corner of the screen.
Reticle Types
1 2 3 4 5 6 7
