Powering O and Entering Standby Mode
To power o the RICOHYBRID:
1. Long press the Power Button. The shutdown screen will open,
showing a 3-second countdown.
2. Continue holding the Power Button until the 3-second
countdown completes.
3. “Data saving...” appears on the screen and the RICOHYBRID will
shut down automatically after saving.
NOTE: Releasing the Power
Button at any time before the
countdown reaches zero will stop the shutdown process and the
rifle scope will enter standby mode. Short press the Power
Button to exit standby mode.
WARNING: If using an external power supply, do not remove the
power supply when saving data, as the data may not be saved.
STANDBY MODE
Standby mode may be activated to conserve battery life.
Manually Enter Standby Mode
The user may enter standby mode manually at any time.
1. To enter standby from the home screen:
a. Long press the Power Button to bring up the shutdown
screen.
b. Release the Power Button during the 3-second shutdown
countdown to manually enter standby mode.
2. Short press the Power Button to exit standby.
Set the RICOHYBRID to Enter Standby Mode Automatically
The rifle scope may be set to automatically enter standby mode.
1. In the main menu, select the standby time, 5, 10, 20, 30, or
60minutes. Once set, the RICOHYBRID will automatically enter
standby according to the specified length of inactivity.
2. Short press the Power Button to exit standby.
NOTES:
• When 5min, 10min, 20min, 30min, or 60min is selected:
• The RICOHYBRID will enter standby mode automatically
when it is tilted up or down at an angle of more than 70° or
left or right at an angle of more than 30°.
• The RICOHYBRID will not enter standby mode while it is in a
level firing position.
• When o is selected, standby mode is turned o and the rifle
scope will operate until the battery runs out.
• See Main Menu > Standby on page36 for instructions.
Adjusting the Focus
ADJUSTING THE DIOPTER/EYEPIECE
1. Rotate the eyepiece diopter adjustment ring (8) at the rear of the
rifle scope right or left until the user interface is clear.
2. Look closely to ensure all screen symbols, the status bar, and
the reticle appear sharp and in focus. No additional diopter
adjustments are required unless the user wishes to make
changes.
NOTES:
• After the initial adjustment, there is no need to rotate the
eyepiece adjustment ring (8) for long distances or other
conditions.
• If necessary during standard use, the objective lens focus
knob(2) may be rotated to adjust fine focus on the target object
being observed. See Focusing the Objective Lens below.
FOCUSING THE OBJECTIVE LENS
To adjust the focus on the target object:
1. Rotate the objective lens focus knob(2) left or right to adjust fine
focus.
NOTE:
Re-adjusting the focus will be necessary if the distance to
the target changes.
Activating / Deactivating the Reticle
The reticle may be inactive when the RICOHYBRID is powered on for
the first time. To activate the reticle, or to deactivate it at a later time:
1. From the home screen, long press the Rotary Encoder to enter
the main menu.
2. Rotate the Rotary Encoder to select the settings menu item.
3. Short press the Rotary Encoder to enter the settings submenu.
4. Long press the Rotary Encoder and the Brightness Button at
the same time for 3 seconds to activate the reticle and hidden
reticle and zeroing menu items.
