21
A
How to Remove the Oven Door
For a more thorough clean, you can remove the oven door.
Choose the remove and assemble method.
Proceed as follows:
• Oven door structures 1 remove and assemble procedure:
• Open the door to the full extent (fig. 1)
• Open the lever A completely on the left and right hinges
(fig. 2)
• Hold the door as shown in fig. 3
• Gently close the door (fig. 3) until left and right hinge
levers A are hooked to part B of the door (fig. 4)
• Withdraw the hinge hooks from their location following
arrow C (fig. 4)
• Rest the door on a soft surface;
• To replace the door, repeat the above steps
in reverse order.
Removing the Inner Pane of Glass
• Double oven door: Remove the seal G by unscrew
the no. 2 bolts (fig. 5)
• Gently pull out the inner pane of glass (fig. 6)
• Clean the glass with an appropriate cleaner.
Dry thoroughly, and place on a soft surface.
• Now you can also clean the inside of the outer glass.
Fig. 2Fig. 1
Fig. 3 Fig. 4
A
B
C
Fig. 5
Fig. 6
Cleaning & Maintenance (Continued)
