ENGLISHESPAÑOLFRANÇAIS
–3–
GETTING TO KNOW YOUR AIR CONDITIONER
UNIT FEATURES
1. Metal cabinet
2. Upper guide
3. Curtain (window filler)
4. Up/down directional air blades
5. Le/right directional air blades
6. Control panel
7. Power cord
8. Front grille
9. Le/right directional air blades
10. Air intake
11. Fresh Air/External air intake
(optional, not on all units)
ELECTRONIC CONTROL PANEL
NOTE: The visual appearance of your control panel may dier significantly; rest assured that
the functionality remains identical.
1. Digital display
Fan mode: indicates present room temperature
Cool/Dry mode: indicates desired temperature
Timer mode: indicates the remaining time
NOTE: if the temperature sensor fails, the display will continu-
ously read 77°F or 25°C
2. Remote Control sensor
3. Operating mode
The current operating mode is indicated by the adja-
cent LEDs.
4. Timer button
Press this button while the unit is running to program a
shutdown time set using the up and down arrow buttons.
Press this button while the unit is in standby mode to
program a startup time set using the up and down ar-
row buttons.
5. Speed button
Choose the fan speed rate between High, Medium, and Low.
6. Mode button
Select the unit operating mode between Cool, Dry, and Fan.
