INSTALLER
27
INSTALLATION
Instructions of cabinet and refrigerator
1. Install the door handle onto the cabinet door.
2. Measure the distance from xing plate to cabinet top with a tape.
3. Firstly, install the two cabinet doors on the Product, loose and remove the hexagon ange
nut. Take down the upper xing plate on refrigerator door (refer to Fig. 6).
4. Fixation of upper xing plate and cabinet door: Place the upper xing plate onto the ca-
binet door, until the distance between the xing plate and upper edge of cabinet door
reaches the distance that is measured in the previous step; put the tooling plate against
the door handle side, then put the upper xing plate against the limit surface of tooling
plate, conrm the position of xing plate on the cabinet door; x the upper xing plate and
cabinet door with at head self tapping screws. (Refer to Fig. 7)
Box xing frame
Box xing frame
Upper xing plate
Cabinet door
Cabinet xing plate
Piastar di ssaggio
(Fig.6)
(Fig.7)
5. Fixation of cabinet xing plate and door: Put the tooling plate against the cabinet handle
side, and put one side against the upper xing plate; put the cabinet xing plate into the
corresponding slot of tooling plate, then x the cabinet xing plate and cabinet door with
at head self tapping screws.
