27
INSTALLER
CORRECT POSITIONING
The hood should be placed at a minimum distance of
65 cm for the wall-mounted models and 75 cm for the
island/roof models. It could be that Your specic hob re-
quires the range hood to be placed at a greater distan-
ce: always refer to the manufacturer’s instructions hand-
book for further information.
The installation site must:
- be well ventilated and not exposed to weather conditions;
- have a temperature between +16 e i +32 °C
(90°F) and an humidity below 60% (any variation from
the aforementioned values could accelerate the usual
decay time of the carbon lters decay or limit the overall
performance of the hood);
-comply with all the applicable regulation from the User’s
country in terms of indoor air quality, electrical system
security and work safety;
- be suitable for the preparation of food.
For correct installation, refer to the drawings on
page 17 to 25.
The equipment must be installed in a way that
ensures easy access to electric connections. Do
not use any electric wire or other electric devi-
ces to extend the original power cord. Please inspect the
existing wall sockets or power cords of your kitchen and
place the hood accordingly;
The fastening kit (screws and plugs) supplied with
the hood can only be used on masonry wall. For
installation on other types of walls consider alter-
native fastening systems, taking into account the strength
of the wall and the weight of the hood.
Do not place the equipment near ammable
materials or ammable substance containers
(e.g. partition walls, gas cylinders, etc.), to
avoid re hazards.
All the installation operations, assembly, con-
nection to the electric power supply and extraor-
dinary maintenance must only be carried out by
qualied personnel, authorised by the Distributor or Ma-
nufacturer, in accordance with the legal requirements of
the country of installation and in compliance with equip-
ment and workplace safety regulations.
The equipment must only be installed by respon-
sible and experienced adults, without physical
impairment and in perfect psychological and
physical condition.
During installation, anyone and any objects not
involved in the assembly operations must be kept
away from the area.
Before starting the assembly operations, make
sure that all the necessary tools are available
and in good working order.
ELECTRIC CONNECTION
The electric connection can only be carried out
by qualied personnel (electrician).
The cable and the internal hood cables must
not be replaced or modied. Before connecting
the equipment to the power mains:
- read the safety instructions provided at the beginning
of this manual;
- make sure that the electric system installed complies
with the local regulations of the country of installation;
- make sure that the electric system installed is suitable for
the characteristics of the equipment being installed (see
the details on the data plate).
Refer to chapter “How to read product label” on
page 26 for further information on the data plate.
The equipment is supplied with the power supply cable
already attached: connect a suitable plug for the load to
the cable (the plug must comply with current standards).
Remember the following:
- yellow- green cable: earth;
- blue cable: neutral;
- brown cable: phase
Always install a circuit breaker for quick discon-
nection.The earth cable must be not interrupted
by the circuit breaker.
If the power cord is faulty, it should be replaced with
another one with identical features. To prevent all kinds of
risks, such replacement must be carried out by the Ma-
nufacturer, its technical support service, or in any case
by a similarly qualied individual. The Manufacturer is not
liable for any damage resulting from the use of unau-
thorized or aftermarket spares. Before any interventions
inside the hood, disconnect the
electric power supply.
Avoid winding the cable on itself if too long. Make
sure that the cable is not in contact with liquids,
sharp or hot objects (temperatures exceeding
>70°C ), or corrosive substances.
INSTALLATION
