A1. ATTACH THE MOUNTING PLATE TO THE WALL
Attach the plate to the wall using toggle bolts. At least
one wood screw must be used to attach the plate to a wall
stud.
1. Remove the toggle wings from the bolts.
2. Insert the bolts into the mounting plate through the
holes designated to go into drywall and reattach the
toggle wings to
3
⁄
4
″(19mm)ontoeachbolt.
To use toggle bolts:
Spacing for Toggles
MoreThanWall
Thickness
Toggle
Wings
Mounting
Plate
Toggle
Bolt
Wall
Bolt End
3. Place the mounting plate against the wall and insert
the toggle wings into the holes in the wall to mount the
plate.
NOTE: Before tightening toggle bolts and wood screw,
make sure the bott m of the mounting plate touch the
bottom
ofthecabinetwhenpushedushagainstthewall
and that the plate is properly centered under the cabinet.
CAUTION:Becarefultoavoidpinchingngersbe-
tween the back of the mounting plate and the wall.
4. Tighten all bolts. Pull the plate away from the wall to
help tighten the bolts.
A2. USE TOP CABINET TEMPLATE FOR PREPARA-
TION OF TOP CABINET
You need to drill holes for the top support screws and a
holelargeenoughforthepowercordtotthrough.
• ReadtheinstructionsontheTOPCABINETTEMPLATE.
• Tapeitunderneaththetopcabinet.
NOTE: Adjust top template accordingly if the microwave
is being spaced out from the wall due to cabinet depth
(including cabinet doors) of more than 13".
• Drilltheholes,followingtheinstructionsontheTOP
CABINET TEMPLATE.
CAUTION:Wearsafetygoggleswhendrillingholesinthe
cabinet bottom.
A3. CHECK BLOWER PLATE
Blower Plate
• Placethemicrowaveinitsuprightposition,withthetop
of the unit facing up.
• Checktoseethattheblowerplateiscorrectlyinstalled
on the unit.
A4. MOUNT THE MICROWAVE OVEN
FOREASIERINSTALLATIONANDPERSONALSAFETY,WE
RECOMMENDTHATTWOPEOPLEINSTALLTHISMICRO-
WAVEOVEN.
IMPORTANT: Do not grip or use the handle or heat
shield during installation. Do not remove the cardboard
spacers between the heat shield and door.
NOTE: If your cabinet is metal, use the nylon grommet
around the power cord hole to prevent cutting of the cord.
NOTE:Werecommendusingllerblocksifthecabinet
front hangs below the cabinet bottom shelf.
IMPORTANT: If
llerblocksarenotused,casedamage
may occur from overtightening screws.
EN
NOTE: If the cabinet depth, including the cabinet doors,
from wall using adequate materials supporting 150 lbs
> 13”
> (33cm)
Spacer is
needed
Outside exhaust or
recirculating when
cabinet depth <13”
< 13”
< (33cm)
Cabinet
¼”
min
clearance
¼” min
clearance
Cabinet
9
Outside exhaust or
recirculang when
cabinet depth >13"
is more than 13",
to allow proper top vent air exhaust/intake.
then the unit must be spaced out
