NOTE:Whenmountingthe
microwave oven, thread power
cord through hole in bottom
of top cabinet. Keep it tight
throughoutSteps1–3.Donot
pinch cord or lift oven by pulling
cord.
1. Lift microwave, tilt it
forward, and hook slots
at back bottom edge
onto four lower tabs of
mounting plate.
2. Rotate front of oven
up against cabinet
bottom.
3.Insertaself-aligningscrewthroughtopcentercabinet
hole. Temporarily secure the oven by turning the screw
at least two full turns after the threads have engaged.
(It will be completely tightened later.) Be sure to keep
power cord tight. Be careful not to pinch the cord,
especially when mounting ush to bottom of
cabinet.
Cabinet Front
Cabinet Bottom Shelf
Self-AligningScrew
Microwave Oven Top
Equivalent
to Depth
of Cabinet
Recess
4. Attach the microwave oven to the top cabinet.
5.Insert2self-aligningscrewsthrough
outer top cabinet holes. Turn two full
turns on each screw.
6. Tighten center
screw completely.
7. Tighten the outer two screws to the top of the micro-
waveoven.(Whiletighteningscrews,holdthemicro-
wave oven in place against the wall and the top cabi-
net.)
with the microwave.
A5. INSTALLING OR CHANGE THE CHARCOAL FIL-
A5.1 Unplug microwave oven or disconnect power.
A5.2
Open the microwave door and remove the two
vent mounting screws l; ocated on top of the
microwaveusinga#1Phillipsscrewdriver.
Charcoal
Filter
A5.3 Removethecharcoallterbypushingthetop
ofthelterinwards,thenpullitforwardout
from the unit.
EN
TER (LAGAN and MEDELNIVÅ)
NOTE: ThecharcoallterisfactoryinstalledinUPPSEENDE.
Formodelswithouttherecirculationlteraccessdoor,fol-
lowthesestepstoreplaceorinstallacharcoallter.
installed and for replacement information.
Refer to the to see if yours is factory
8.Installgreaselters.SeetheAdvice & Instructionspacked
Advice & Instructions
Filler Piece
10
