ENGLISH
OPERATING THE MONITOR 29
*
Support NFC reader ISO/IEC 14443 A, ISO/IEC 14443 B, ISO/IEC 15693, MIFARE 1K / 4K,
MIFARE DESFire, Sony FeliCa (According to ISO/IEC 18092 (Ecma 340) standard.)
Device
Device
Microphone
Camera
none
NFC
Ambient light sensor
PIR motion sensor
CEC
X
Stylus pickup sensor
Enter annotation mode
General
Device
Channel
System
Admin
Adjustment Item Problem / Option Button to Press
Microphone
You can select the microphone to use in the microphone device connected
to the machine and test whether the microphone input is normal.
Camera
You can select the camera to use from the camera device connected to the
machine and display a preview of the camera.
NFC *
Turn on the NFC module of the device. Once enabled, new NFC
cards can be added.
Turn o the NFC module of the device.
Shutdown by NFC Enabled / Disabled
Boot by NFC Enabled / Disabled
Wakeup by NFC Enabled / Disabled
Enable touch by NFC Enabled / Disabled
CEC
Once enabled, a function realised through the HDMI interface, allowing
control and communication between connected devices. Currently only
one-way CEC function is supported.
Ambient light
sensor
When turned on, the screen's backlight brightness will automatically adjust
according to the ambient light.
Stylus pickup
sensor
When enabled, if a pen-lifting action is detected, three quick access
buttons for whiteboard, annotation, and no action will appear.
PIR motion sensor
When enabled, the screen will automatically wake up when someone
approaches the device.
