VVB301 VVB302 VVB305 VVB306
12
Basic condition monitoring
VVB301 / VVB305
DataScience condition monitoring
VVB302 / VVB306
• v-RMS (configurable: x, y or z axis, magnitude)
• a-Peak (configurable: x, y or z axis, magnitude)
• a-RMS (configurable: x, y or z axis, magnitude)
• Crest (configurable: x, y or z axis, magnitude)
• Temperature
• Unbalance event
• Virtual switching output (v-ou1)
• v-RMS (x axis)
• v-RMS (y axis)
• v-RMS (z axis)
• v-RMS (magnitude)
• a-Peak (x axis)
• a-Peak (y axis)
• a-Peak (z axis)
• a-peak (magnitude)
• a-RMS (x axis)
• a-RMS (y axis)
• a-RMS (z axis)
• a-RMS (magnitude)
• Temperature
• Unbalance event
• Bearing event (BearingScout)
• Virtual switching output
(v-ou1)
Hysteresis function
SP
rP
v-RMS
t: Time
SP: Setpoint
rP: Reset point
HY: Hysteresis
Hno: Hysteresis NO (normally open)
Hnc: Hysteresis NC (normally closed)
Window function
v-RMS
FH
FL
t: Time
FH: Upper limit value
FL: Lower limit value
FE: Window
Fno: Window NO (normally open)
Fnc: Window NC (normally closed)
For both switching outputs, a switch-on and switch-off delay can be set.
Both switching outputs (OU1 or OU2) can optionally be set to inactive.
A switching delay can be set for unbalance and bearing events.
A hysteresis and window function is not possible, as only one limit value can be set via IO-Link
(no setpoint and reset point).
