Je bekijkt pagina 16 van 24
VSE163 Diagnostic electronics with Modbus TCP interface
16 © ifm electronic gmbh 11704143 / 00 09 / 2025
Input (PLC)
Read time DINT 4 bytes Read device time (UTC)
PROFINET devices:
U32:0x00ssmmhh
EtherNetIP devices:
U32:0x00hhmmss
EtherCAT devices:
U32:0x00hhmmss
MODBUS devices:
U32:0x00hhmmss
Placeholder
<placeholder> Byte xx byte Placeholder for fieldbus
transmission
Output (PLC)
Source Data type/
Byte order/
Unit
Data size Fieldbus representation
External inputs
<input name> • Real or DINT with factor
• Big or
Little Endian
4 bytes Set value of the external
input (External_xx)
Objects (time domain, frequency domain)
<object name>
Baseline • Real or DINT with factor
• Big or
Little Endian
• Has a unit (default SI unit)
4 bytes Limits -
set unit-based baseline
for time and frequency
objects to adjust damage
limits
General
Variant Byte 1 byte Set current variant
(0...31)
Do self-test Byte 1 byte Execute self-test
Note
A value change from 0 to
≠ 0 starts the self-test
After completion of the
self-test, the unit auto-
matically switches to the
“Monitoring” system
mode
Set time DINT 4 bytes Set time (always UTC for-
mat)
PROFINET devices:
U32:0x00ssmmhh
EtherNet/IP devices:
U32:0x00hhmmss
EtherCAT devices:
U32:0x00hhmmss
MODBUS devices:
U32:0x00hhmmss
Set counter ID Byte 1 byte Set the ID of the counter
(1…32)
