Diagnostic electronics with Modbus TCP interface VSE163
© ifm electronic gmbh 11704143 / 00 09 / 2025 15
Input (PLC)
<alarm name> Byte 1 byte Alarm state
Configuration as NC
No alarm: 1
Alarm: 0
Configuration as NO
No alarm: 0
Alarm: 1
General
Variant Byte 1 byte Value of the active variant
(0...31)
System mode Byte 1 byte Current system mode of
the device
0x00:
reserved
0x01:
supervise (normal moni-
toring)
0x02:
set-up (parameter set-
ting)
0x03:
measure (spectrum, raw
data)
0x04:
start-up (system booting)
0x05:
self-test (self-test active)
Self-test
result
Byte 1 byte Bit pattern
Bit1 - sensor 1
Bit2 - sensor 2
Bit3 - sensor 3
Bit4 - sensor 4
Note on evaluation
0x00:
Sensors OK
0x01:
sensor 1 self-test failed
0x02:
sensor 2 self-test failed
0x04:
sensor 3 self-test failed
0x08:
sensor 4 self-test failed
0x0F:
sensor1…4 self-test
failed
Current queue level Byte 1 byte Current queue level of
the internal device com-
munication
Queue overflow coun-
ter
• DINT
• Big or
Little Endian
4 bytes Overflow counter of the
internal device communi-
cation
Checksum error coun-
ter
• DINT
• Big or
Little Endian
4 bytes Checksum error counter
of the internal device
communication
