Condition monitoring sensor with CANopen interface VMB301
39
16 Signal filtering
Filtering for internal signal processing and calculation of process values.
Index Subindex Description Type Access
0x2040 0x00 Type DC filter
Filter for the DC component (static accel-
eration) - relevant for the calculation of all
characteristic values except displacement
(d-Peak2Peak)
u8 rw 0: 2 Hz high pass
1: 10 Hz high pass
2: 20 Hz high pass
3: 40 Hz high pass
0x2041 0x00 Acceleration type
Filter for the acceleration characteristic
values (a-RMS, a-Peak, Crest)
u8 rw 0: Unfiltered
1: 1000 Hz low pass
2: 2000 Hz low pass
3: 3000 Hz low pass
4: 5000 Hz low pass
5: 1000 Hz high pass
6: 2000 Hz high pass
7: 3000 Hz high pass
8: 5000 Hz high pass
9: 500...1500 Hz band-
pass
10: 1500...2500 Hz band-
pass
11: 2500...5000 Hz band-
pass
0x2042 0x00 Type: speed
Filter for the speed parameters (v-RMS)
u8 rw 0: 1000 Hz low pass
0x2043 0x00 Type: path
Filter for the vibration path
(d-Peak2Peak).
The characteristic value d-Peak2Peak is
fixed at 1 Hz regardless of the selected
DC filter.
u8 rw 0: 100 Hz low pass
0x2054 0x01 Type: rolling bearing frequency factors
Configuration of the damage frequency
factors of the installed rolling bearing (in-
ner ring, outer ring and rolling element)
u32 rw Inner ring - default: 0.0
0x02 u32 rw Outer ring - default: 0.0
0x03 u32 rw Rolling elements - default:
0.0
If one of the rolling bearing frequency factors (index 2054) remains at the default value [0], a
generic BearingScout™ bearing characteristic value is formed.
