SUHxxx Ultrasonic flow meter without display
36 © ifm electronic gmbh 11661449 / 01 07 / 2025
▪ BtB (Back to Box): reset to factory settings. The following is reset:
– All changed application-specific parameters
– All writeable unit identification parameters such as Application Specific Tag, Function Tag or
Location Tag.
– Diagnostic parameters, status parameters, events.
After the Back to Box reset, the sensor suspends communication and measurement operation
until the voltage is interrupted. The IO-Link data storage is not triggered.
We recommend documenting your own settings in the chapter Factory setting before carrying
out a reset.
10.4 Diagnostic functions
The device offers a range of diagnostic functions.
Diagnostic messages can be provided via an output signal:
Switching signal Diagnosis [ 23].
In addition, the diagnostic information described below is available via the IO-Link interface.
10.4.1 Read totaliser values
For the totalisers, the following values can be read at any time via the IO-Link interface:
Totaliser values Vol.1 and Vol.2
▪ Current flow quantity (=consumed quantity since the last totaliser reset)
▪ Value before the last totaliser reset
▪ Time since the last totaliser reset
Lifetime totaliser (for the entire operating time)
▪ Flow quantity in preferred direction (= positive direction of flow)
▪ Flow quantity in non-preferred direction (= negative direction of flow)
Flow direction [ 32]
10.4.2 Memory
The unit stores the maximum and minimum measured process values.
The current value can be read via the IO-Link interface.
Selectable values:
▪ Lo.F: Minimum value memory for volumetric flow
▪ Hi.F: Maximum value memory for volumetric flow
▪ Lo.T: Minimum value memory for temperature
▪ Hi.T: Maximum value memory for temperature
It makes sense to delete the memories as soon as the unit operates under normal operating
conditions for the first time.
