SUHxxx Ultrasonic flow meter without display
26 © ifm electronic gmbh 11661449 / 01 07 / 2025
10.2.4 Analogue signal
The device provides an analogue signal proportional to the process value.
Within the measuring range the analogue signal is between 4...20 mA.
The measuring range can be scaled between -100% and 100% of the final value of the measuring range.
A negative flow value means flow against the flow direction set under [Fdir] [ 32].
▪ ASP2 determines at which measured value the output signal is 4mA.
▪ AEP2 determines at which measured value the output signal is 20mA.
Minimum distance between ASP2 and AEP2 = 20 % of the final value of the measuring range.
If the measured value is outside the measuring range or in the event of an internal error, the current signal
indicated in the following figure is provided.
