Ultrasonic flow meter without display SUHxxx
© ifm electronic gmbh 11661449 / 01 07 / 2025 25
Pulse signal totaliser [ 25]
OUT1 and OUT2 cannot be used simultaneously for the consumed quantity monitoring.
10.2.3.1 Switching signal totaliser
A switching signal can be provided for consumed quantity monitoring.
When totaliser Vol.1 has totalled the flow quantity (pulse value) set under ImPS, the output provides a
switching signal.
The flow direction is taken into account when totalling the flow quantity [ 34].
The output remains switched until a totaliser reset is carried out. When the totaliser has been reset,
metering starts again.
The totaliser is reset automatically or manually.
The conditions for the totaliser reset and the switching signal can be set via the parameter rTo:
▪ rTo = OFF:
– The totaliser is only reset with a manual reset or after overflow.
– The output is switched when the totaliser has reached the flow quantity ImPS.
▪ rTo = …h / d / w (hours / days / weeks):
– The totaliser is automatically reset after the set time.
– The output is only switched when the totaliser reaches the flow quantity ImPS by the set time.
The totalisers can be reset manually at any time via the rTox parameter. Totaliser Vol.1 can
additionally be reset via an external signal at pin 2.
Totaliser reset [ 34]
Parameters to be set:
oux = ImP; ImPSx; ImPRx = no
10.2.3.2 Pulse signal totaliser
Pulse signals can be provided for consumed quantity monitoring.
Pulse signals are not available via the IO-Link interface.
The output provides a pulse signal each time totaliser Vol.1 has totalled the flow quantity (pulse value) set
under ImPS.
The flow direction is taken into account when totalling the flow quantity [ 34].
The pulse signal consists of a short switching on and off of the output.
Parameters to be set:
oux = ImP; ImPSx; ImPRx = yes
