SU2x5x SU6x5x SU7x5x SU8x5x SU9x5x Ultrasonic flow meter
30
9.3.12 Reset the unit
The unit can be reset in 2 ways:
• [APPL] (application reset): reset of the parameter settings. The following is reset:
– All changed application-specific parameters
If IO-Link data storage is activated, this triggers a parameter update in the master. This writes
the parameters configured in the master to the device again. An application reset may therefore
be ineffective.
• [BtB] (Back to Box): reset to factory settings. The following is reset:
– All changed application-specific parameters
– All writeable unit identification parameters such as [Application Specific Tag], [Function Tag] or
[Location Tag].
– Diagnostic parameters, status parameters, events.
After the Back to Box reset, the sensor suspends communication and measurement operation
until the voltage is interrupted. The IO-Link data storage is not triggered.
We recommend documenting your own settings in the chapter Factory setting before carrying
out a reset.
9.4 Diagnostic functions
The device offers a range of diagnostic functions.
Diagnostic messages can be provided via an output signal:
Ò Switching signal Diagnosis (Ò/18).
In addition, the diagnostic information described below is available via the IO-Link interface.
9.4.1 Read totaliser values
For the totalisers, the following values can be read at any time via the IO-Link interface:
Totaliser values Vol.1 and Vol.2
• Current flow quantity (=consumed quantity since the last totaliser reset)
• Value before the last totaliser reset
• Time since the last totaliser reset
Lifetime totaliser (for the entire operating time)
• Flow quantity in preferred direction (= positive direction of flow)
• Flow quantity in non-preferred direction (= negative direction of flow)
Ò Flow direction (Ò/27)
9.4.2 Memory
The unit stores the maximum and minimum measured process values.
The current value can be read via the IO-Link interface.
Selectable values:
• [Lo.F]: Minimum value memory for volumetric flow
• [Hi.F]: Maximum value memory for volumetric flow
• [Lo.T]: Minimum value memory for temperature
