Wiring of PP2000
For hard-wiring of the PP2000: Disconnect power before
connecting the unit.
For mobile use of the PP2000 after installation of the sensor:
Connect PP2000, sensor and plant via the plug and socket
connections only!
Do not disconnect these connections while live.
Faults displayed during operation:
24
3
Teach signal and acknowledgement signal with pnp operation = +U
B
Teach signal and acknowledgement signal with npn operation = -U
B
3
4
2
1
BU
BK
WH
BN
PP2000PP754x
1
L-
L
+
3
4
2
BU
BK
WH
BN
OU1
OU2
2
1
4
3
3
4
2
1
2 x Out
p-switching n-switching
L-
L
+
3
4
2
1
BU
BK
WH
BN
PP2000PP754x
OUT
IN (Teach)
3
4
2
1
BU
BK
WH
BN
2
1
4
3
3
4
2
1
Teach function, 1 x Out
p-switching n-switching
overload = (above measuring range of the sensor)
(flashing) = short-circuit in switching output 1/ 2;
the respective output is switched off.
underload = (below measuring range of the sensor)
