PG17xx Electronic manometer
44 © ifm electronic gmbh 11601190 / 01 07 / 2025
11.4.6.1 Parameter setting via unit keys: Calibration
Call up the menu EF > CFG.
Select CGA.P and set the gradient of the measuring characteristic in per cent.
11.4.7 Switch-point logic
The switch-point logic of the switching output can be set.
Selectable values:
• H.Act = High active = normally open
• L.Act = Low active = normally closed
11.4.7.1 Parameter setting via the device keys: Switch-point logic
Switching signal channel SSC1.1 is set using the device keys. Further switching signal chan-
nels can be set via the IO-Link interface.
Go to EF > OU1.
Select LoGc and set the switch-point logic.
11.4.8 Switching delay
The switching output can be set to switch and reset with a delay time.
Selectable values:
• dS: switch-on delay for switching output OUT1 in seconds.
• dr: switch-off delay for switching output OUT1 in seconds.
Setting range:
0…50 seconds
11.4.8.1 Parameter setting via the device keys: Switching delay
Switching signal channel SSC1.1 is set using the device keys. Further switching signal chan-
nels can be set via the IO-Link interface.
Go to EF > OU1.
Select dS and set the delay for switching OUT1 in seconds.
Select dr and set the delay for resetting OUT1 in seconds.
11.4.9 Energy-saving mode
The device can be operated in energy-saving mode.
The energy-saving mode is activated using parameter ECO.m.
The following applies in energy-saving mode:
• The brightness of the display is reduced to 25%.
• The status LED has the setting NoTI, i.e. it only lights in case of a warning or an error.
