PG17xx Electronic manometer
34 © ifm electronic gmbh 11601190 / 01 07 / 2025
The parameters for each switching signal channel can be set individually.
The switch point mode, switch points and the switch point logic are set when the switching signal channel
parameters are set.
Switch point mode
You can choose between the following switch point modes according to the IO-Link smart sensor profile ‒
Function Class “Object Detection”:
• Deactivated
• Single Point Mode
• Two Point Mode
• Window Mode
The switching signal channel changes to the active state depending on the process data value (PDV).
The active state is above the switch point in Single Point Mode and Two Point Mode and
within the window section in Window Mode.
Switch point logic
By setting the switch point logic High active or Low active, you can specify which value the switching
signal channel has in the active state:
• High active: The switching signal channel is “high” in the active state (= ON = normally open = 1)
• Low active: The switching signal channel is “low” in the active state (= OFF = normally closed = 0)
The following figures show the status of the switching signal channels depending on the switch point
mode, switch point logic and process data value (PDV).
Deactivated
If the Deactivated switch point mode is set for a switching signal channel, then the switching signal chan-
nel will permanently have the following value regardless of the process value:
• For switch point logic High active: permanently “low”.
• For switch point logic Low active: permanently “high”.
low
PDV
0
Fig.12: Deactivated / High active
high
PDV
1
Fig.13: Deactivated / Low active
Single Point Mode
Only one switch point (SP1) is manually set or taught.
The reset point (SP1-H) results from the switch point and the set hysteresis.
When teaching, the switch point is set below the taught process value (TP1) by the hysteresis.
