Electronic manometer PG17xx
© ifm electronic gmbh 11601190 / 01 07 / 2025 27
Parameter Explanation
CGA.P Calibration factor in % for adapting the curve of measured values to the application
ECO.m Energy-saving mode ECO or energy-saving mode OFF.
Output configuration OU1menu:
BACk
[EF]
OU1
CFG
OU2
DIS
DIA
SIM
RES
LoGc
ModE
tSP1
SP1
tSP2
ou1
SP2
HYSt
dS
dr
BACk
[OU1]
SSC1│OFF
H.Act│L.Act
YES│no
2-P│WInd│1-P│DEac
----
YES│no
----│Auto
----
----
----
On│OFF
FOU1
Main menu
Parameter Explanation
ou1 Output function for output OUT1: SSC1 = switching signal with parameter settings for
SSC1.1; OFF.
LoGc Switch-point logic: H.Act = high active or L.Act = low active
ModE Switch point mode: 1-P = single point mode; 2-P = two point mode; WInd = window
mode; Deac = deactivated.
tSP1 Teach switch point SP1
SP1 Switch point 1
tSP2 Teach switch point SP2
SP2 Switch point 2
HYSt Hysteresis
dS Switching delay for change into active state (in seconds)
