PG17xx Electronic manometer
30
10.2 Parameter setting via IO-Link
The device parameters can be set via the IO-Link interface in the following ways, for example:
• Parameter setting via a suitable parameter setting software, e.g. ifm moneo|configure
• Parameter setting via a PLC
• Parameter setting via an IIoT application
Requirements for parameter setting via the IO-Link interface:
ü The Input Output Device Description (IODD) for the device in case of parameter setting via a
parameter setting software, see documentation.ifm.com
ü The IO-Link interface description (PDF) for the device in case of parameter setting via a PLC or
IIoT application, see documentation.ifm.com
ü An IO-Link master
u Connect the IO-Link master to the parameter setting software, the PLC or the IIoT application.
u Connect the device to a suitable free port of the IO-Link master.
u Set the port of the IO-Link master to the IO-Link operating mode.
w The device changes to the IO-Link mode.
u Change the parameter settings in the software.
u Write the parameter settings to the device.
Support for system integration and parameter setting via IO-Link:
Ò Manual of the parameter setting software (e.g. moneo)
Ò Explanations and startup packages at ifm.com/cnt/io-link-system-integration.
10.3 Output configuration
10.3.1 Digital switching signal
The device provides digital switching signals via switching signal channels (SSC = Switching Signal
Channel).
The device has 2 digital switching signal channels SSCx.1 and SSCx.2 for each process value:
• SSC1.1 and SSC1.2 = switching signal channels for pressure
• SSC2.1 and SSC2.2 = switching signal channels for temperature
Explanation of the numbering of the switching signal channels SSCx.y:
x = process value; y = switching signal channel
Switching signal channel SSC1.1 can be evaluated via the IO-Link interface and the hardware output.
The other switching signal channels can only be evaluated and configured via the IO-Link interface.
The switching signal channel SSC1.1 is permanently assigned to the physical hardware output OUT1.
The parameters for each switching signal channel can be set individually.
The switch point mode, switch points and the switch point logic are set when the switching signal
channel parameters are set.
Switch point mode
You can choose between the following switch point modes according to the IO-Link smart sensor
profile ‒ Function Class “Object Detection”:
• [Deactivated]
• [Single Point Mode]
